| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_010T01_9000002046_13892cztM0_level2.evt | modeM0/AS1A04_010T01_9000002046_13892cztM0_level2_quad_clean.evt |
| Size (bytes) | 543,985,920 | 100,396,800 |
| Size | 518.8 MB | 95.7 MB |
| Events in quadrant A | 3,178,290 | 664,093 |
| Events in quadrant B | 3,220,532 | 667,106 |
| Events in quadrant C | 3,907,524 | 644,313 |
| Events in quadrant D | 5,727,433 | 611,155 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13754 | 3 |
| B | 0 | 13867 | 2 |
| C | 0 | 15939 | 2 |
| D | 0 | 21552 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6505 | 74 | 1.137586% |
| B | 6505 | 74 | 1.137586% |
| C | 6505 | 260 | 3.996925% |
| D | 6505 | 528 | 8.116833% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7571 | 6506 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7571 | 6506 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7570 | 6505 | 123 | 123 | 1.62% | 1.89% |  |
| D | 7570 | 6505 | 484 | 484 | 6.39% | 7.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 23 | 18075 | 103.59 | 817 | 798 | 166.8 |
| A | 1 | 162 | 11879 | 66.44 | 817 | 798 | 166.8 |
| A | 0 | 226 | 8341 | 45.23 | 817 | 798 | 166.8 |
| B | 4 | 80 | 23166 | 144.51 | 807 | 788 | 154.9 |
| B | 12 | 111 | 18304 | 113.11 | 807 | 788 | 154.9 |
| B | 11 | 111 | 16004 | 98.26 | 807 | 788 | 154.9 |
| C | 3 | 233 | 857763 | 4703.45 | 781 | 784 | 182.2 |
| C | 13 | 61 | 5608 | 26.48 | 781 | 784 | 182.2 |
| C | 12 | 4 | 2109 | 7.27 | 781 | 784 | 182.2 |
| D | 1 | 52 | 2154798 | 11759.76 | 775 | 758 | 183.2 |
| D | 8 | 195 | 205430 | 1117.39 | 775 | 758 | 183.2 |
| D | 13 | 189 | 151822 | 824.72 | 775 | 758 | 183.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
