| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_010T02_9000002048_13899cztM0_level2.evt | modeM0/AS1A04_010T02_9000002048_13899cztM0_level2_quad_clean.evt |
| Size (bytes) | 580,639,680 | 85,798,080 |
| Size | 553.7 MB | 81.8 MB |
| Events in quadrant A | 3,661,344 | 525,272 |
| Events in quadrant B | 3,553,118 | 529,734 |
| Events in quadrant C | 3,527,163 | 530,118 |
| Events in quadrant D | 6,339,304 | 495,668 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15910 | 3 |
| B | 0 | 15443 | 2 |
| C | 0 | 15399 | 2 |
| D | 0 | 23993 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7427 | 137 | 1.844621% |
| B | 7427 | 167 | 2.248553% |
| C | 7427 | 68 | 0.915578% |
| D | 7427 | 499 | 6.718729% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7678 | 7428 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7678 | 7428 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7678 | 7428 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7678 | 7428 | 487 | 487 | 6.34% | 6.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 169167 | 908.63 | 893 | 870 | 185.2 |
| A | 9 | 143 | 42588 | 225.23 | 893 | 870 | 185.2 |
| A | 1 | 162 | 10388 | 51.39 | 893 | 870 | 185.2 |
| B | 0 | 214 | 24968 | 139.07 | 891 | 867 | 173.3 |
| B | 12 | 111 | 21268 | 117.72 | 891 | 867 | 173.3 |
| B | 3 | 209 | 18621 | 102.44 | 891 | 867 | 173.3 |
| C | 3 | 233 | 128467 | 621.48 | 872 | 877 | 205.3 |
| C | 13 | 61 | 6242 | 26.13 | 872 | 877 | 205.3 |
| C | 3 | 202 | 2047 | 5.7 | 872 | 877 | 205.3 |
| D | 13 | 122 | 1860950 | 9210.41 | 847 | 825 | 202.0 |
| D | 1 | 52 | 940715 | 4653.87 | 847 | 825 | 202.0 |
| D | 13 | 189 | 114429 | 562.51 | 847 | 825 | 202.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
