| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_012T02_9000002050_13914cztM0_level2.evt | modeM0/AS1A04_012T02_9000002050_13914cztM0_level2_quad_clean.evt |
| Size (bytes) | 598,844,160 | 94,095,360 |
| Size | 571.1 MB | 89.7 MB |
| Events in quadrant A | 4,537,415 | 575,067 |
| Events in quadrant B | 3,826,053 | 586,259 |
| Events in quadrant C | 3,756,779 | 589,868 |
| Events in quadrant D | 5,487,490 | 556,253 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18762 | 3 |
| B | 0 | 16538 | 2 |
| C | 0 | 16415 | 2 |
| D | 0 | 21606 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7788 | 348 | 4.468413% |
| B | 7788 | 289 | 3.710837% |
| C | 7788 | 158 | 2.028762% |
| D | 7788 | 356 | 4.571135% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8354 | 7790 | 101 | 101 | 1.21% | 1.30% |  |
| B | 8354 | 7790 | 3 | 3 | 0.04% | 0.04% |  |
| C | 8354 | 7790 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8354 | 7789 | 142 | 142 | 1.70% | 1.82% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 835979 | 4293.01 | 952 | 929 | 194.5 |
| A | 8 | 15 | 19941 | 97.74 | 952 | 929 | 194.5 |
| A | 1 | 162 | 14878 | 71.71 | 952 | 929 | 194.5 |
| B | 4 | 173 | 32364 | 168.04 | 953 | 928 | 187.1 |
| B | 4 | 80 | 23771 | 122.11 | 953 | 928 | 187.1 |
| B | 12 | 111 | 23632 | 121.37 | 953 | 928 | 187.1 |
| C | 3 | 233 | 95685 | 429.47 | 938 | 941 | 220.6 |
| C | 13 | 61 | 6728 | 26.23 | 938 | 941 | 220.6 |
| C | 14 | 234 | 2816 | 8.5 | 938 | 941 | 220.6 |
| D | 13 | 122 | 1116024 | 5019.5 | 917 | 891 | 222.2 |
| D | 5 | 222 | 419490 | 1884.22 | 917 | 891 | 222.2 |
| D | 1 | 52 | 291424 | 1307.76 | 917 | 891 | 222.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
