| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_225T01_9000002062_13967cztM0_level2.evt | modeM0/AS1A04_225T01_9000002062_13967cztM0_level2_quad_clean.evt |
| Size (bytes) | 461,733,120 | 107,792,640 |
| Size | 440.3 MB | 102.8 MB |
| Events in quadrant A | 3,326,867 | 714,768 |
| Events in quadrant B | 3,577,299 | 741,115 |
| Events in quadrant C | 3,200,853 | 707,853 |
| Events in quadrant D | 3,459,305 | 669,824 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13761 | 3 |
| B | 0 | 14666 | 2 |
| C | 0 | 13280 | 2 |
| D | 0 | 14395 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6175 | 97 | 1.570850% |
| B | 6175 | 131 | 2.121457% |
| C | 6175 | 23 | 0.372470% |
| D | 6175 | 62 | 1.004049% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8836 | 6178 | 3 | 3 | 0.03% | 0.05% |  |
| B | 8836 | 6178 | 20 | 20 | 0.23% | 0.32% |  |
| C | 8836 | 6178 | 1 | 1 | 0.01% | 0.02% |  |
| D | 8836 | 6178 | 33 | 33 | 0.37% | 0.53% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 111 | 156342 | 957.85 | 811 | 796 | 162.4 |
| A | 8 | 15 | 21228 | 125.82 | 811 | 796 | 162.4 |
| A | 1 | 162 | 13864 | 80.47 | 811 | 796 | 162.4 |
| B | 0 | 189 | 86892 | 570.18 | 819 | 801 | 151.0 |
| B | 10 | 245 | 66674 | 436.28 | 819 | 801 | 151.0 |
| B | 3 | 64 | 57416 | 374.96 | 819 | 801 | 151.0 |
| C | 3 | 233 | 134177 | 738.92 | 785 | 790 | 180.5 |
| C | 13 | 61 | 5753 | 27.49 | 785 | 790 | 180.5 |
| C | 6 | 253 | 5563 | 26.44 | 785 | 790 | 180.5 |
| D | 1 | 52 | 151591 | 741.38 | 766 | 752 | 203.5 |
| D | 8 | 195 | 106957 | 522.0 | 766 | 752 | 203.5 |
| D | 10 | 199 | 44655 | 215.79 | 766 | 752 | 203.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
