| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_038T02_9000002068_14001cztM0_level2.evt | modeM0/AS1A04_038T02_9000002068_14001cztM0_level2_quad_clean.evt |
| Size (bytes) | 679,521,600 | 143,910,720 |
| Size | 648.0 MB | 137.2 MB |
| Events in quadrant A | 3,806,766 | 984,070 |
| Events in quadrant B | 4,391,354 | 986,434 |
| Events in quadrant C | 4,045,874 | 952,138 |
| Events in quadrant D | 7,792,394 | 878,331 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16887 | 4 |
| B | 0 | 18457 | 3 |
| C | 0 | 17418 | 3 |
| D | 0 | 28623 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8018 | 217 | 2.706411% |
| B | 8018 | 390 | 4.864056% |
| C | 8018 | 256 | 3.192816% |
| D | 8018 | 1035 | 12.908456% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8449 | 8022 | 10 | 10 | 0.12% | 0.12% |  |
| B | 8449 | 8022 | 52 | 52 | 0.62% | 0.65% |  |
| C | 8449 | 8022 | 13 | 13 | 0.15% | 0.16% |  |
| D | 8449 | 8022 | 632 | 632 | 7.48% | 7.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 89342 | 461.82 | 945 | 922 | 191.5 |
| A | 8 | 15 | 42286 | 216.04 | 945 | 922 | 191.5 |
| A | 15 | 69 | 14660 | 71.75 | 945 | 922 | 191.5 |
| B | 10 | 16 | 314837 | 1753.74 | 941 | 916 | 179.0 |
| B | 0 | 189 | 100381 | 555.67 | 941 | 916 | 179.0 |
| B | 0 | 219 | 90101 | 498.24 | 941 | 916 | 179.0 |
| C | 14 | 220 | 224674 | 1066.17 | 914 | 915 | 209.9 |
| C | 3 | 233 | 209747 | 995.05 | 914 | 915 | 209.9 |
| C | 12 | 4 | 26207 | 120.51 | 914 | 915 | 209.9 |
| D | 1 | 52 | 2173685 | 9817.6 | 870 | 847 | 221.3 |
| D | 13 | 104 | 1037234 | 4682.74 | 870 | 847 | 221.3 |
| D | 10 | 157 | 538250 | 2428.16 | 870 | 847 | 221.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
