| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_064T01_9000002070_14009cztM0_level2.evt | modeM0/AS1G08_064T01_9000002070_14009cztM0_level2_quad_clean.evt |
| Size (bytes) | 475,200,000 | 104,757,120 |
| Size | 453.2 MB | 99.9 MB |
| Events in quadrant A | 2,945,572 | 716,105 |
| Events in quadrant B | 3,442,920 | 711,827 |
| Events in quadrant C | 2,972,706 | 708,315 |
| Events in quadrant D | 4,633,861 | 628,383 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12487 | 2 |
| B | 0 | 14143 | 1 |
| C | 0 | 12490 | 1 |
| D | 0 | 17511 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5832 | 69 | 1.183128% |
| B | 5832 | 144 | 2.469136% |
| C | 5832 | 56 | 0.960219% |
| D | 5832 | 554 | 9.499314% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7073 | 5834 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7073 | 5834 | 43 | 43 | 0.61% | 0.74% |  |
| C | 7073 | 5834 | 5 | 5 | 0.07% | 0.09% |  |
| D | 7073 | 5834 | 422 | 422 | 5.97% | 7.23% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 36750 | 238.18 | 753 | 738 | 151.2 |
| A | 8 | 15 | 11614 | 71.93 | 753 | 738 | 151.2 |
| A | 0 | 226 | 6748 | 39.75 | 753 | 738 | 151.2 |
| B | 10 | 16 | 349819 | 2534.92 | 738 | 721 | 137.7 |
| B | 0 | 189 | 53070 | 380.12 | 738 | 721 | 137.7 |
| B | 4 | 142 | 37653 | 268.18 | 738 | 721 | 137.7 |
| C | 3 | 233 | 89254 | 525.82 | 733 | 740 | 168.3 |
| C | 0 | 207 | 16580 | 94.1 | 733 | 740 | 168.3 |
| C | 14 | 234 | 11103 | 61.56 | 733 | 740 | 168.3 |
| D | 10 | 157 | 1040562 | 6422.18 | 685 | 670 | 161.9 |
| D | 1 | 52 | 573469 | 3537.5 | 685 | 670 | 161.9 |
| D | 8 | 195 | 174715 | 1074.87 | 685 | 670 | 161.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
