| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_002T01_9000002072_14033cztM0_level2.evt | modeM0/AS1G08_002T01_9000002072_14033cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,047,951,360 | 146,128,320 |
| Size | 999.4 MB | 139.4 MB |
| Events in quadrant A | 6,186,128 | 888,975 |
| Events in quadrant B | 6,244,971 | 902,047 |
| Events in quadrant C | 6,388,201 | 898,330 |
| Events in quadrant D | 12,033,386 | 830,742 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 268 | 0 |
| B | 0 | 268 | 0 |
| C | 0 | 268 | 0 |
| D | 0 | 268 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27012 | 4 |
| B | 0 | 26973 | 3 |
| C | 0 | 26959 | 3 |
| D | 0 | 44749 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 13098 | 147 | 1.122309% |
| B | 13098 | 153 | 1.168117% |
| C | 13098 | 78 | 0.595511% |
| D | 13098 | 919 | 7.016338% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 14644 | 13102 | 43 | 43 | 0.29% | 0.33% |  |
| B | 14644 | 13102 | 2 | 2 | 0.01% | 0.02% |  |
| C | 14644 | 13102 | 7 | 7 | 0.05% | 0.05% |  |
| D | 14644 | 13102 | 727 | 727 | 4.96% | 5.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 111 | 98885 | 306.71 | 1563 | 1530 | 317.4 |
| A | 12 | 189 | 34061 | 102.49 | 1563 | 1530 | 317.4 |
| A | 1 | 162 | 16063 | 45.78 | 1563 | 1530 | 317.4 |
| B | 12 | 111 | 37393 | 119.7 | 1560 | 1517 | 299.7 |
| B | 0 | 230 | 35351 | 112.89 | 1560 | 1517 | 299.7 |
| B | 4 | 80 | 34470 | 109.95 | 1560 | 1517 | 299.7 |
| C | 3 | 233 | 411842 | 1153.79 | 1526 | 1535 | 355.6 |
| C | 6 | 253 | 22120 | 57.89 | 1526 | 1535 | 355.6 |
| C | 13 | 61 | 10955 | 26.49 | 1526 | 1535 | 355.6 |
| D | 1 | 52 | 3728410 | 10251.7 | 1470 | 1433 | 363.5 |
| D | 13 | 104 | 2338053 | 6427.28 | 1470 | 1433 | 363.5 |
| D | 10 | 157 | 129741 | 352.93 | 1470 | 1433 | 363.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
