| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_002T01_9000002072_14034cztM0_level2.evt | modeM0/AS1G08_002T01_9000002072_14034cztM0_level2_quad_clean.evt |
| Size (bytes) | 490,821,120 | 67,204,800 |
| Size | 468.1 MB | 64.1 MB |
| Events in quadrant A | 3,198,717 | 394,109 |
| Events in quadrant B | 3,345,138 | 397,264 |
| Events in quadrant C | 3,315,150 | 396,622 |
| Events in quadrant D | 4,547,855 | 376,754 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13820 | 3 |
| B | 0 | 14122 | 2 |
| C | 0 | 13829 | 2 |
| D | 0 | 17978 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6746 | 61 | 0.904240% |
| B | 6746 | 75 | 1.111770% |
| C | 6746 | 44 | 0.652238% |
| D | 6746 | 196 | 2.905425% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7592 | 6748 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7592 | 6748 | 5 | 5 | 0.07% | 0.07% |  |
| C | 7592 | 6748 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7592 | 6748 | 137 | 137 | 1.80% | 2.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 18036 | 103.27 | 820 | 803 | 166.9 |
| A | 15 | 69 | 10355 | 57.24 | 820 | 803 | 166.9 |
| A | 0 | 226 | 7230 | 38.52 | 820 | 803 | 166.9 |
| B | 0 | 230 | 50192 | 315.64 | 814 | 793 | 156.5 |
| B | 10 | 244 | 49350 | 310.26 | 814 | 793 | 156.5 |
| B | 3 | 64 | 26383 | 163.51 | 814 | 793 | 156.5 |
| C | 3 | 233 | 220014 | 1180.05 | 794 | 798 | 185.8 |
| C | 13 | 61 | 5713 | 26.46 | 794 | 798 | 185.8 |
| C | 3 | 202 | 1752 | 5.14 | 794 | 798 | 185.8 |
| D | 1 | 52 | 1270161 | 6804.95 | 782 | 763 | 186.5 |
| D | 10 | 157 | 138514 | 738.45 | 782 | 763 | 186.5 |
| D | 13 | 189 | 61060 | 323.24 | 782 | 763 | 186.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
