| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_055T01_9000002076_14078cztM0_level2.evt | modeM0/AS1G08_055T01_9000002076_14078cztM0_level2_quad_clean.evt |
| Size (bytes) | 475,459,200 | 99,665,280 |
| Size | 453.4 MB | 95.0 MB |
| Events in quadrant A | 3,523,910 | 649,459 |
| Events in quadrant B | 3,425,003 | 653,906 |
| Events in quadrant C | 3,124,575 | 636,639 |
| Events in quadrant D | 3,876,185 | 616,723 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14530 | 2 |
| B | 0 | 14180 | 1 |
| C | 0 | 13602 | 1 |
| D | 0 | 15489 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6630 | 89 | 1.342383% |
| B | 6630 | 93 | 1.402715% |
| C | 6630 | 52 | 0.784314% |
| D | 6630 | 115 | 1.734540% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7541 | 6632 | 15 | 15 | 0.20% | 0.23% |  |
| B | 7541 | 6632 | 14 | 14 | 0.19% | 0.21% |  |
| C | 7541 | 6632 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7541 | 6632 | 43 | 43 | 0.57% | 0.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 207255 | 1280.61 | 803 | 786 | 161.2 |
| A | 12 | 189 | 116922 | 720.33 | 803 | 786 | 161.2 |
| A | 15 | 222 | 77749 | 477.36 | 803 | 786 | 161.2 |
| B | 10 | 16 | 55326 | 365.24 | 802 | 783 | 149.3 |
| B | 0 | 189 | 51263 | 338.03 | 802 | 783 | 149.3 |
| B | 4 | 80 | 36053 | 236.18 | 802 | 783 | 149.3 |
| C | 3 | 233 | 53557 | 292.56 | 782 | 785 | 180.4 |
| C | 0 | 207 | 19286 | 102.57 | 782 | 785 | 180.4 |
| C | 13 | 61 | 5775 | 27.66 | 782 | 785 | 180.4 |
| D | 8 | 195 | 359794 | 1918.2 | 774 | 754 | 187.2 |
| D | 1 | 52 | 169945 | 903.92 | 774 | 754 | 187.2 |
| D | 2 | 152 | 102790 | 545.14 | 774 | 754 | 187.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
