| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_229T01_9000002096_14186cztM0_level2.evt | modeM0/AS1A04_229T01_9000002096_14186cztM0_level2_quad_clean.evt |
| Size (bytes) | 500,535,360 | 74,197,440 |
| Size | 477.3 MB | 70.8 MB |
| Events in quadrant A | 3,357,243 | 458,802 |
| Events in quadrant B | 3,534,572 | 476,027 |
| Events in quadrant C | 3,641,775 | 440,179 |
| Events in quadrant D | 4,187,962 | 422,377 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13879 | 3 |
| B | 0 | 14387 | 2 |
| C | 0 | 14695 | 2 |
| D | 0 | 16739 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6436 | 124 | 1.926663% |
| B | 6436 | 134 | 2.082039% |
| C | 6436 | 131 | 2.035426% |
| D | 6436 | 176 | 2.734618% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7612 | 6438 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7612 | 6438 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7612 | 6438 | 48 | 48 | 0.63% | 0.75% |  |
| D | 7612 | 6438 | 90 | 90 | 1.18% | 1.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 27581 | 155.0 | 855 | 837 | 172.5 |
| A | 9 | 143 | 17411 | 96.06 | 855 | 837 | 172.5 |
| A | 12 | 96 | 14031 | 76.47 | 855 | 837 | 172.5 |
| B | 0 | 219 | 97888 | 603.91 | 855 | 838 | 160.7 |
| B | 3 | 209 | 54823 | 335.93 | 855 | 838 | 160.7 |
| B | 0 | 189 | 23742 | 142.52 | 855 | 838 | 160.7 |
| C | 0 | 207 | 275305 | 1467.74 | 813 | 819 | 187.0 |
| C | 3 | 233 | 178984 | 952.69 | 813 | 819 | 187.0 |
| C | 5 | 96 | 11139 | 55.18 | 813 | 819 | 187.0 |
| D | 8 | 195 | 386129 | 1989.75 | 811 | 793 | 193.7 |
| D | 10 | 157 | 374775 | 1931.12 | 811 | 793 | 193.7 |
| D | 2 | 152 | 135289 | 694.49 | 811 | 793 | 193.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
