| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_084T01_9000002100_14212cztM0_level2.evt | modeM0/AS1G08_084T01_9000002100_14212cztM0_level2_quad_clean.evt |
| Size (bytes) | 472,608,000 | 107,354,880 |
| Size | 450.7 MB | 102.4 MB |
| Events in quadrant A | 3,220,167 | 716,221 |
| Events in quadrant B | 3,306,991 | 725,852 |
| Events in quadrant C | 3,241,454 | 702,832 |
| Events in quadrant D | 4,121,587 | 671,587 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13448 | 3 |
| B | 0 | 13625 | 2 |
| C | 0 | 13636 | 2 |
| D | 0 | 16284 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6223 | 64 | 1.028443% |
| B | 6223 | 77 | 1.237345% |
| C | 6223 | 57 | 0.915957% |
| D | 6223 | 190 | 3.053190% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7434 | 6225 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7434 | 6225 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7434 | 6225 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7434 | 6225 | 92 | 92 | 1.24% | 1.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 63260 | 387.68 | 811 | 794 | 161.1 |
| A | 8 | 15 | 31844 | 192.7 | 811 | 794 | 161.1 |
| A | 0 | 226 | 7191 | 39.7 | 811 | 794 | 161.1 |
| B | 4 | 97 | 42273 | 279.48 | 808 | 791 | 148.4 |
| B | 0 | 189 | 27616 | 180.73 | 808 | 791 | 148.4 |
| B | 0 | 219 | 26564 | 173.64 | 808 | 791 | 148.4 |
| C | 3 | 233 | 147281 | 812.26 | 794 | 800 | 180.3 |
| C | 13 | 61 | 5651 | 26.9 | 794 | 800 | 180.3 |
| C | 3 | 203 | 1884 | 6.01 | 794 | 800 | 180.3 |
| D | 5 | 222 | 399543 | 2158.35 | 785 | 768 | 184.8 |
| D | 8 | 195 | 367776 | 1986.41 | 785 | 768 | 184.8 |
| D | 10 | 199 | 241086 | 1300.71 | 785 | 768 | 184.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
