| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_014T01_9000002104_14282cztM0_level2.evt | modeM0/AS1G08_014T01_9000002104_14282cztM0_level2_quad_clean.evt |
| Size (bytes) | 472,276,800 | 93,902,400 |
| Size | 450.4 MB | 89.6 MB |
| Events in quadrant A | 3,144,988 | 611,000 |
| Events in quadrant B | 3,745,832 | 613,855 |
| Events in quadrant C | 3,456,628 | 591,315 |
| Events in quadrant D | 3,519,030 | 579,181 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13391 | 3 |
| B | 0 | 15214 | 2 |
| C | 0 | 14184 | 2 |
| D | 0 | 14539 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6429 | 18 | 0.279981% |
| B | 6429 | 140 | 2.177633% |
| C | 6429 | 16 | 0.248872% |
| D | 6429 | 41 | 0.637735% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7580 | 6431 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7580 | 6431 | 80 | 80 | 1.06% | 1.24% |  |
| C | 7580 | 6431 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7580 | 6431 | 54 | 54 | 0.71% | 0.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 40464 | 244.51 | 805 | 787 | 162.3 |
| A | 8 | 15 | 8760 | 49.13 | 805 | 787 | 162.3 |
| A | 0 | 226 | 7035 | 38.5 | 805 | 787 | 162.3 |
| B | 10 | 245 | 219292 | 1445.5 | 799 | 779 | 151.2 |
| B | 15 | 222 | 155166 | 1021.3 | 799 | 779 | 151.2 |
| B | 0 | 229 | 116066 | 762.64 | 799 | 779 | 151.2 |
| C | 3 | 233 | 398117 | 2191.95 | 783 | 787 | 181.3 |
| C | 13 | 61 | 5679 | 26.99 | 783 | 787 | 181.3 |
| C | 7 | 220 | 4273 | 19.23 | 783 | 787 | 181.3 |
| D | 12 | 110 | 332321 | 1791.94 | 780 | 762 | 185.0 |
| D | 8 | 195 | 77243 | 413.35 | 780 | 762 | 185.0 |
| D | 5 | 222 | 71975 | 384.88 | 780 | 762 | 185.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
