| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_014T01_9000002104_14287cztM0_level2.evt | modeM0/AS1G08_014T01_9000002104_14287cztM0_level2_quad_clean.evt |
| Size (bytes) | 561,231,360 | 81,397,440 |
| Size | 535.2 MB | 77.6 MB |
| Events in quadrant A | 3,294,703 | 524,161 |
| Events in quadrant B | 3,510,556 | 524,487 |
| Events in quadrant C | 3,424,443 | 498,262 |
| Events in quadrant D | 6,330,607 | 468,254 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13440 | 2 |
| B | 0 | 14190 | 1 |
| C | 0 | 13700 | 1 |
| D | 0 | 23065 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6439 | 76 | 1.180308% |
| B | 6439 | 114 | 1.770461% |
| C | 6439 | 48 | 0.745457% |
| D | 6439 | 899 | 13.961795% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7645 | 6440 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7645 | 6441 | 13 | 13 | 0.17% | 0.20% |  |
| C | 7645 | 6441 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7645 | 6441 | 724 | 724 | 9.47% | 11.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 43191 | 253.13 | 835 | 819 | 167.4 |
| A | 8 | 15 | 29005 | 168.38 | 835 | 819 | 167.4 |
| A | 11 | 29 | 8098 | 43.48 | 835 | 819 | 167.4 |
| B | 0 | 229 | 163140 | 1040.81 | 820 | 801 | 156.0 |
| B | 0 | 230 | 32611 | 203.95 | 820 | 801 | 156.0 |
| B | 4 | 142 | 31022 | 193.76 | 820 | 801 | 156.0 |
| C | 3 | 233 | 321484 | 1763.42 | 795 | 801 | 181.9 |
| C | 13 | 61 | 5576 | 26.26 | 795 | 801 | 181.9 |
| C | 3 | 202 | 1844 | 5.74 | 795 | 801 | 181.9 |
| D | 5 | 222 | 2678836 | 14682.03 | 771 | 755 | 182.4 |
| D | 13 | 122 | 573327 | 3139.01 | 771 | 755 | 182.4 |
| D | 10 | 199 | 62898 | 340.69 | 771 | 755 | 182.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
