| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_130T03_9000002108_14302cztM0_level2.evt | modeM0/AS1A04_130T03_9000002108_14302cztM0_level2_quad_clean.evt |
| Size (bytes) | 438,390,720 | 76,256,640 |
| Size | 418.1 MB | 72.7 MB |
| Events in quadrant A | 3,021,850 | 478,456 |
| Events in quadrant B | 3,357,571 | 483,818 |
| Events in quadrant C | 3,227,339 | 468,478 |
| Events in quadrant D | 3,262,944 | 459,997 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12467 | 2 |
| B | 0 | 13556 | 1 |
| C | 0 | 12842 | 1 |
| D | 0 | 13482 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5983 | 99 | 1.654688% |
| B | 5983 | 145 | 2.423533% |
| C | 5983 | 56 | 0.935985% |
| D | 5983 | 111 | 1.855257% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7064 | 5984 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7064 | 5984 | 31 | 31 | 0.44% | 0.52% |  |
| C | 7064 | 5985 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7064 | 5984 | 35 | 35 | 0.50% | 0.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 43128 | 273.97 | 763 | 748 | 154.7 |
| A | 8 | 15 | 24929 | 156.32 | 763 | 748 | 154.7 |
| A | 11 | 29 | 14382 | 88.14 | 763 | 748 | 154.7 |
| B | 0 | 229 | 242809 | 1693.26 | 749 | 730 | 143.0 |
| B | 4 | 142 | 51211 | 353.1 | 749 | 730 | 143.0 |
| B | 0 | 189 | 48092 | 331.28 | 749 | 730 | 143.0 |
| C | 3 | 233 | 361027 | 2143.3 | 734 | 738 | 168.1 |
| C | 10 | 22 | 5832 | 30.3 | 734 | 738 | 168.1 |
| C | 13 | 61 | 5197 | 26.53 | 734 | 738 | 168.1 |
| D | 12 | 110 | 178352 | 1012.29 | 742 | 726 | 175.5 |
| D | 5 | 222 | 95829 | 541.99 | 742 | 726 | 175.5 |
| D | 10 | 199 | 79332 | 447.98 | 742 | 726 | 175.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
