| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_149T01_9000002118_14378cztM0_level2.evt | modeM0/AS1A04_149T01_9000002118_14378cztM0_level2_quad_clean.evt |
| Size (bytes) | 534,654,720 | 105,569,280 |
| Size | 509.9 MB | 100.7 MB |
| Events in quadrant A | 3,352,637 | 684,318 |
| Events in quadrant B | 3,469,580 | 688,111 |
| Events in quadrant C | 3,838,569 | 678,178 |
| Events in quadrant D | 5,051,824 | 654,482 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14683 | 2 |
| B | 0 | 14980 | 1 |
| C | 0 | 15483 | 1 |
| D | 0 | 20030 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7065 | 168 | 2.377919% |
| B | 7065 | 163 | 2.307148% |
| C | 7065 | 81 | 1.146497% |
| D | 7065 | 311 | 4.401982% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7241 | 7066 | 20 | 20 | 0.28% | 0.28% |  |
| B | 7241 | 7066 | 14 | 14 | 0.19% | 0.20% |  |
| C | 7241 | 7067 | 1 | 1 | 0.01% | 0.01% |  |
| D | 7241 | 7066 | 81 | 81 | 1.12% | 1.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 86769 | 508.13 | 832 | 815 | 169.2 |
| A | 8 | 15 | 47133 | 273.82 | 832 | 815 | 169.2 |
| A | 15 | 69 | 16190 | 90.89 | 832 | 815 | 169.2 |
| B | 0 | 229 | 96701 | 603.15 | 829 | 806 | 159.0 |
| B | 0 | 189 | 33508 | 205.69 | 829 | 806 | 159.0 |
| B | 0 | 219 | 31470 | 192.87 | 829 | 806 | 159.0 |
| C | 3 | 233 | 663796 | 3554.28 | 807 | 809 | 186.5 |
| C | 8 | 128 | 9539 | 46.8 | 807 | 809 | 186.5 |
| C | 13 | 61 | 5850 | 27.02 | 807 | 809 | 186.5 |
| D | 12 | 110 | 1568969 | 8018.85 | 799 | 776 | 195.6 |
| D | 2 | 120 | 188755 | 961.22 | 799 | 776 | 195.6 |
| D | 15 | 0 | 115900 | 588.68 | 799 | 776 | 195.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
