| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_222T01_9000002132_14472cztM0_level2.evt | modeM0/AS1A04_222T01_9000002132_14472cztM0_level2_quad_clean.evt |
| Size (bytes) | 469,955,520 | 124,292,160 |
| Size | 448.2 MB | 118.5 MB |
| Events in quadrant A | 2,986,852 | 833,319 |
| Events in quadrant B | 4,085,298 | 829,983 |
| Events in quadrant C | 3,072,281 | 851,876 |
| Events in quadrant D | 3,662,229 | 811,598 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12999 | 3 |
| B | 0 | 16440 | 2 |
| C | 0 | 13337 | 2 |
| D | 0 | 15251 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6261 | 12 | 0.191663% |
| B | 6261 | 354 | 5.654049% |
| C | 6261 | 12 | 0.191663% |
| D | 6261 | 107 | 1.708992% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7517 | 6263 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7517 | 6263 | 231 | 231 | 3.07% | 3.69% |  |
| C | 7517 | 6263 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7517 | 6263 | 79 | 79 | 1.05% | 1.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 67273 | 444.42 | 747 | 732 | 149.7 |
| A | 8 | 15 | 20369 | 131.15 | 747 | 732 | 149.7 |
| A | 4 | 2 | 9509 | 58.62 | 747 | 732 | 149.7 |
| B | 0 | 182 | 725070 | 5260.03 | 743 | 725 | 137.7 |
| B | 0 | 189 | 208810 | 1511.07 | 743 | 725 | 137.7 |
| B | 15 | 222 | 93387 | 672.89 | 743 | 725 | 137.7 |
| C | 3 | 233 | 146447 | 858.76 | 744 | 749 | 169.7 |
| C | 0 | 207 | 19508 | 110.57 | 744 | 749 | 169.7 |
| C | 13 | 61 | 5324 | 26.97 | 744 | 749 | 169.7 |
| D | 12 | 110 | 471909 | 2559.09 | 729 | 711 | 184.1 |
| D | 10 | 199 | 129426 | 699.05 | 729 | 711 | 184.1 |
| D | 2 | 152 | 115553 | 623.71 | 729 | 711 | 184.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
