| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_083T01_9000002134_14476cztM0_level2.evt | modeM0/AS1G08_083T01_9000002134_14476cztM0_level2_quad_clean.evt |
| Size (bytes) | 481,360,320 | 96,235,200 |
| Size | 459.1 MB | 91.8 MB |
| Events in quadrant A | 3,260,560 | 616,566 |
| Events in quadrant B | 3,617,841 | 619,648 |
| Events in quadrant C | 3,401,055 | 612,262 |
| Events in quadrant D | 3,830,940 | 586,440 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14254 | 3 |
| B | 0 | 15194 | 2 |
| C | 0 | 14657 | 2 |
| D | 0 | 16244 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6874 | 63 | 0.916497% |
| B | 6874 | 120 | 1.745708% |
| C | 6874 | 55 | 0.800116% |
| D | 6874 | 200 | 2.909514% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9290 | 6876 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9290 | 6876 | 14 | 14 | 0.15% | 0.20% |  |
| C | 9290 | 6876 | 3 | 3 | 0.03% | 0.04% |  |
| D | 9290 | 6877 | 130 | 130 | 1.40% | 1.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 52215 | 306.36 | 831 | 814 | 167.8 |
| A | 0 | 226 | 7491 | 39.8 | 831 | 814 | 167.8 |
| A | 12 | 194 | 6202 | 32.11 | 831 | 814 | 167.8 |
| B | 0 | 85 | 110578 | 706.86 | 835 | 814 | 155.3 |
| B | 10 | 252 | 86721 | 553.23 | 835 | 814 | 155.3 |
| B | 15 | 222 | 47684 | 301.84 | 835 | 814 | 155.3 |
| C | 3 | 233 | 124815 | 664.41 | 810 | 813 | 186.6 |
| C | 0 | 207 | 105896 | 563.04 | 810 | 813 | 186.6 |
| C | 13 | 61 | 5878 | 27.14 | 810 | 813 | 186.6 |
| D | 10 | 199 | 278923 | 1471.14 | 789 | 769 | 189.1 |
| D | 15 | 0 | 223838 | 1179.8 | 789 | 769 | 189.1 |
| D | 2 | 14 | 147019 | 773.51 | 789 | 769 | 189.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
