| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_066T01_9000002138_14506cztM0_level2.evt | modeM0/AS1G08_066T01_9000002138_14506cztM0_level2_quad_clean.evt |
| Size (bytes) | 475,493,760 | 82,704,960 |
| Size | 453.5 MB | 78.9 MB |
| Events in quadrant A | 3,030,842 | 525,587 |
| Events in quadrant B | 3,380,532 | 532,463 |
| Events in quadrant C | 3,112,231 | 533,956 |
| Events in quadrant D | 4,441,112 | 464,999 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13219 | 2 |
| B | 0 | 14210 | 1 |
| C | 0 | 13229 | 1 |
| D | 0 | 17624 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6408 | 49 | 0.764669% |
| B | 6408 | 117 | 1.825843% |
| C | 6408 | 57 | 0.889513% |
| D | 6408 | 686 | 10.705368% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7129 | 6410 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7129 | 6410 | 30 | 30 | 0.42% | 0.47% |  |
| C | 7129 | 6410 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7129 | 6410 | 394 | 394 | 5.53% | 6.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 42217 | 267.38 | 768 | 751 | 155.1 |
| A | 11 | 29 | 12503 | 75.78 | 768 | 751 | 155.1 |
| A | 4 | 2 | 10978 | 65.95 | 768 | 751 | 155.1 |
| B | 0 | 85 | 163236 | 1100.91 | 766 | 747 | 147.6 |
| B | 10 | 245 | 86431 | 580.53 | 766 | 747 | 147.6 |
| B | 0 | 189 | 37315 | 247.76 | 766 | 747 | 147.6 |
| C | 3 | 233 | 129224 | 731.92 | 757 | 762 | 175.5 |
| C | 0 | 207 | 18466 | 100.87 | 757 | 762 | 175.5 |
| C | 10 | 22 | 11715 | 62.41 | 757 | 762 | 175.5 |
| D | 10 | 199 | 1476165 | 8210.44 | 709 | 691 | 179.7 |
| D | 12 | 110 | 249935 | 1386.95 | 709 | 691 | 179.7 |
| D | 2 | 234 | 24816 | 134.25 | 709 | 691 | 179.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
