| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_066T01_9000002138_14516cztM0_level2.evt | modeM0/AS1G08_066T01_9000002138_14516cztM0_level2_quad_clean.evt |
| Size (bytes) | 478,728,000 | 75,602,880 |
| Size | 456.6 MB | 72.1 MB |
| Events in quadrant A | 3,539,922 | 470,475 |
| Events in quadrant B | 3,460,834 | 476,769 |
| Events in quadrant C | 3,356,449 | 465,884 |
| Events in quadrant D | 3,720,597 | 443,471 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 14 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14534 | 3 |
| B | 0 | 14445 | 2 |
| C | 0 | 13773 | 2 |
| D | 0 | 15072 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6198 | 79 | 1.274605% |
| B | 6198 | 76 | 1.226202% |
| C | 6198 | 33 | 0.532430% |
| D | 6198 | 159 | 2.565344% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7464 | 6200 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7464 | 6200 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7464 | 6200 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7464 | 6200 | 117 | 117 | 1.57% | 1.89% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 326466 | 1971.42 | 823 | 806 | 165.2 |
| A | 12 | 189 | 24351 | 142.53 | 823 | 806 | 165.2 |
| A | 9 | 143 | 17438 | 100.68 | 823 | 806 | 165.2 |
| B | 0 | 219 | 39289 | 251.97 | 827 | 809 | 152.7 |
| B | 0 | 197 | 36208 | 231.79 | 827 | 809 | 152.7 |
| B | 0 | 189 | 35973 | 230.25 | 827 | 809 | 152.7 |
| C | 3 | 233 | 231527 | 1259.55 | 800 | 805 | 183.2 |
| C | 13 | 61 | 5637 | 26.38 | 800 | 805 | 183.2 |
| C | 0 | 207 | 2632 | 9.97 | 800 | 805 | 183.2 |
| D | 10 | 199 | 486021 | 2480.29 | 789 | 768 | 195.6 |
| D | 10 | 70 | 92843 | 470.63 | 789 | 768 | 195.6 |
| D | 2 | 120 | 53163 | 267.81 | 789 | 768 | 195.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
