| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_049T01_9000002142_14533cztM0_level2.evt | modeM0/AS1T02_049T01_9000002142_14533cztM0_level2_quad_clean.evt |
| Size (bytes) | 434,689,920 | 115,009,920 |
| Size | 414.6 MB | 109.7 MB |
| Events in quadrant A | 3,216,457 | 763,677 |
| Events in quadrant B | 3,230,250 | 776,802 |
| Events in quadrant C | 3,189,068 | 774,740 |
| Events in quadrant D | 3,105,482 | 733,460 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13711 | 3 |
| B | 0 | 13752 | 2 |
| C | 0 | 13415 | 2 |
| D | 0 | 13731 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6230 | 19 | 0.304976% |
| B | 6230 | 34 | 0.545746% |
| C | 6230 | 14 | 0.224719% |
| D | 6230 | 79 | 1.268058% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7556 | 6232 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7556 | 6232 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7556 | 6232 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7556 | 6232 | 55 | 55 | 0.73% | 0.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 321248 | 2159.56 | 740 | 725 | 148.4 |
| A | 12 | 189 | 25641 | 167.87 | 740 | 725 | 148.4 |
| A | 13 | 248 | 10266 | 64.28 | 740 | 725 | 148.4 |
| B | 0 | 219 | 70313 | 504.21 | 751 | 733 | 138.0 |
| B | 0 | 189 | 62074 | 444.51 | 751 | 733 | 138.0 |
| B | 10 | 245 | 52306 | 373.72 | 751 | 733 | 138.0 |
| C | 3 | 233 | 326634 | 1966.57 | 733 | 737 | 165.7 |
| C | 13 | 61 | 5418 | 28.25 | 733 | 737 | 165.7 |
| C | 14 | 225 | 2605 | 11.27 | 733 | 737 | 165.7 |
| D | 10 | 199 | 251646 | 1450.75 | 717 | 696 | 173.0 |
| D | 12 | 110 | 63258 | 361.67 | 717 | 696 | 173.0 |
| D | 2 | 234 | 23702 | 133.0 | 717 | 696 | 173.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
