| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_049T01_9000002142_14535cztM0_level2.evt | modeM0/AS1T02_049T01_9000002142_14535cztM0_level2_quad_clean.evt |
| Size (bytes) | 536,843,520 | 126,002,880 |
| Size | 512.0 MB | 120.2 MB |
| Events in quadrant A | 3,837,108 | 833,157 |
| Events in quadrant B | 3,649,601 | 838,639 |
| Events in quadrant C | 3,564,707 | 838,190 |
| Events in quadrant D | 4,711,230 | 797,632 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16157 | 3 |
| B | 0 | 15712 | 2 |
| C | 0 | 15453 | 2 |
| D | 0 | 19226 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7301 | 69 | 0.945076% |
| B | 7301 | 101 | 1.383372% |
| C | 7301 | 31 | 0.424599% |
| D | 7301 | 185 | 2.533899% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9072 | 7304 | 1 | 1 | 0.01% | 0.01% |  |
| B | 9072 | 7304 | 5 | 5 | 0.06% | 0.07% |  |
| C | 9072 | 7304 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9072 | 7304 | 202 | 202 | 2.23% | 2.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 497867 | 2920.59 | 845 | 825 | 170.2 |
| A | 12 | 189 | 65681 | 381.09 | 845 | 825 | 170.2 |
| A | 4 | 2 | 8436 | 44.72 | 845 | 825 | 170.2 |
| B | 0 | 189 | 79274 | 484.75 | 852 | 829 | 161.8 |
| B | 0 | 219 | 75858 | 463.64 | 852 | 829 | 161.8 |
| B | 3 | 209 | 53388 | 324.79 | 852 | 829 | 161.8 |
| C | 3 | 233 | 331713 | 1735.36 | 828 | 831 | 190.7 |
| C | 13 | 61 | 6013 | 27.18 | 828 | 831 | 190.7 |
| C | 1 | 5 | 3283 | 12.86 | 828 | 831 | 190.7 |
| D | 12 | 110 | 1145027 | 5860.48 | 814 | 788 | 195.2 |
| D | 10 | 199 | 338891 | 1731.67 | 814 | 788 | 195.2 |
| D | 15 | 0 | 47635 | 239.94 | 814 | 788 | 195.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
