| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_089T01_9000002146_14563cztM0_level2.evt | modeM0/AS1A04_089T01_9000002146_14563cztM0_level2_quad_clean.evt |
| Size (bytes) | 468,132,480 | 99,092,160 |
| Size | 446.4 MB | 94.5 MB |
| Events in quadrant A | 3,338,131 | 641,352 |
| Events in quadrant B | 3,446,445 | 653,109 |
| Events in quadrant C | 3,552,606 | 634,758 |
| Events in quadrant D | 3,400,617 | 620,163 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14134 | 3 |
| B | 0 | 14411 | 2 |
| C | 0 | 14357 | 2 |
| D | 0 | 14390 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6473 | 79 | 1.220454% |
| B | 6473 | 104 | 1.606674% |
| C | 6473 | 59 | 0.911478% |
| D | 6473 | 114 | 1.761162% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7495 | 6475 | 8 | 8 | 0.11% | 0.12% |  |
| B | 7495 | 6475 | 5 | 5 | 0.07% | 0.08% |  |
| C | 7495 | 6475 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7495 | 6475 | 62 | 62 | 0.83% | 0.96% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 98249 | 593.16 | 814 | 798 | 164.3 |
| A | 12 | 189 | 84712 | 510.76 | 814 | 798 | 164.3 |
| A | 0 | 23 | 24634 | 145.08 | 814 | 798 | 164.3 |
| B | 0 | 189 | 87882 | 555.45 | 820 | 801 | 156.8 |
| B | 4 | 173 | 32614 | 202.92 | 820 | 801 | 156.8 |
| B | 0 | 205 | 29063 | 180.27 | 820 | 801 | 156.8 |
| C | 3 | 233 | 416666 | 2229.62 | 802 | 809 | 186.5 |
| C | 13 | 61 | 5817 | 26.85 | 802 | 809 | 186.5 |
| C | 8 | 128 | 4338 | 18.92 | 802 | 809 | 186.5 |
| D | 10 | 199 | 197161 | 933.59 | 792 | 779 | 210.4 |
| D | 12 | 110 | 60050 | 281.77 | 792 | 779 | 210.4 |
| D | 13 | 122 | 43327 | 202.27 | 792 | 779 | 210.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
