| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_043T01_9000002156_14636cztM0_level2.evt | modeM0/AS1A04_043T01_9000002156_14636cztM0_level2_quad_clean.evt |
| Size (bytes) | 603,936,000 | 101,943,360 |
| Size | 576.0 MB | 97.2 MB |
| Events in quadrant A | 4,004,829 | 650,524 |
| Events in quadrant B | 3,987,154 | 648,693 |
| Events in quadrant C | 5,889,988 | 636,736 |
| Events in quadrant D | 3,903,534 | 632,576 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16850 | 3 |
| B | 0 | 16864 | 2 |
| C | 0 | 23113 | 2 |
| D | 0 | 16805 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7454 | 50 | 0.670781% |
| B | 7454 | 94 | 1.261068% |
| C | 7454 | 154 | 2.066005% |
| D | 7454 | 78 | 1.046418% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9480 | 7457 | 1 | 1 | 0.01% | 0.01% |  |
| B | 9480 | 7457 | 6 | 6 | 0.06% | 0.08% |  |
| C | 9480 | 7457 | 6 | 6 | 0.06% | 0.08% |  |
| D | 9480 | 7457 | 53 | 53 | 0.56% | 0.71% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 171063 | 937.23 | 895 | 877 | 181.6 |
| A | 0 | 23 | 89678 | 489.04 | 895 | 877 | 181.6 |
| A | 1 | 178 | 72663 | 395.33 | 895 | 877 | 181.6 |
| B | 0 | 189 | 257669 | 1514.65 | 897 | 873 | 169.5 |
| B | 0 | 230 | 52417 | 304.02 | 897 | 873 | 169.5 |
| B | 0 | 197 | 30663 | 175.71 | 897 | 873 | 169.5 |
| C | 3 | 233 | 2481179 | 12342.47 | 870 | 873 | 201.0 |
| C | 13 | 61 | 6123 | 26.12 | 870 | 873 | 201.0 |
| C | 3 | 234 | 5800 | 24.52 | 870 | 873 | 201.0 |
| D | 10 | 199 | 161476 | 735.04 | 870 | 846 | 218.5 |
| D | 12 | 110 | 149516 | 680.31 | 870 | 846 | 218.5 |
| D | 10 | 70 | 72834 | 329.42 | 870 | 846 | 218.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
