| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_043T01_9000002156_14639cztM0_level2.evt | modeM0/AS1A04_043T01_9000002156_14639cztM0_level2_quad_clean.evt |
| Size (bytes) | 519,943,680 | 97,750,080 |
| Size | 495.9 MB | 93.2 MB |
| Events in quadrant A | 3,461,263 | 627,285 |
| Events in quadrant B | 3,291,198 | 626,219 |
| Events in quadrant C | 4,895,696 | 615,319 |
| Events in quadrant D | 3,632,716 | 613,054 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14943 | 2 |
| B | 0 | 14433 | 1 |
| C | 0 | 19423 | 1 |
| D | 0 | 15896 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6864 | 23 | 0.335082% |
| B | 6864 | 34 | 0.495338% |
| C | 6864 | 35 | 0.509907% |
| D | 6864 | 118 | 1.719114% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7285 | 6866 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7285 | 6866 | 7 | 7 | 0.10% | 0.10% |  |
| C | 7285 | 6866 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7285 | 6866 | 104 | 104 | 1.43% | 1.51% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 130906 | 813.41 | 785 | 768 | 160.0 |
| A | 1 | 162 | 78856 | 488.08 | 785 | 768 | 160.0 |
| A | 0 | 23 | 74244 | 459.25 | 785 | 768 | 160.0 |
| B | 0 | 189 | 95814 | 634.14 | 785 | 765 | 149.9 |
| B | 4 | 173 | 32246 | 210.03 | 785 | 765 | 149.9 |
| B | 10 | 246 | 22825 | 147.18 | 785 | 765 | 149.9 |
| C | 3 | 233 | 1923023 | 10908.72 | 758 | 759 | 176.2 |
| C | 3 | 234 | 14333 | 77.03 | 758 | 759 | 176.2 |
| C | 3 | 232 | 6065 | 30.11 | 758 | 759 | 176.2 |
| D | 10 | 70 | 279976 | 1528.3 | 754 | 733 | 182.7 |
| D | 12 | 110 | 201059 | 1096.39 | 754 | 733 | 182.7 |
| D | 12 | 18 | 108810 | 591.51 | 754 | 733 | 182.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
