| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_020T01_9000002168_14658cztM0_level2.evt | modeM0/AS1G08_020T01_9000002168_14658cztM0_level2_quad_clean.evt |
| Size (bytes) | 209,050,560 | 28,843,200 |
| Size | 199.4 MB | 27.5 MB |
| Events in quadrant A | 1,517,231 | 174,208 |
| Events in quadrant B | 1,421,078 | 172,485 |
| Events in quadrant C | 1,755,255 | 167,165 |
| Events in quadrant D | 1,456,075 | 169,564 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 58 | 0 |
| B | 0 | 58 | 0 |
| C | 0 | 58 | 0 |
| D | 0 | 58 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6194 | 2 |
| B | 0 | 5883 | 1 |
| C | 0 | 7460 | 1 |
| D | 0 | 5963 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2631 | 65 | 2.470544% |
| B | 2631 | 79 | 3.002661% |
| C | 2631 | 57 | 2.166477% |
| D | 2631 | 62 | 2.356518% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3707 | 2632 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3707 | 2632 | 4 | 4 | 0.11% | 0.15% |  |
| C | 3707 | 2632 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3707 | 2632 | 10 | 10 | 0.27% | 0.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 81586 | 1113.93 | 355 | 348 | 72.9 |
| A | 0 | 23 | 26201 | 354.49 | 355 | 348 | 72.9 |
| A | 1 | 162 | 23261 | 314.18 | 355 | 348 | 72.9 |
| B | 4 | 80 | 11480 | 160.42 | 352 | 343 | 69.4 |
| B | 0 | 214 | 8762 | 121.27 | 352 | 343 | 69.4 |
| B | 0 | 205 | 8223 | 113.51 | 352 | 343 | 69.4 |
| C | 3 | 233 | 417427 | 5214.59 | 341 | 344 | 80.0 |
| C | 3 | 234 | 5049 | 58.82 | 341 | 344 | 80.0 |
| C | 13 | 61 | 2519 | 27.19 | 341 | 344 | 80.0 |
| D | 5 | 222 | 92810 | 1124.74 | 343 | 335 | 82.2 |
| D | 12 | 110 | 25957 | 311.63 | 343 | 335 | 82.2 |
| D | 10 | 199 | 16277 | 193.9 | 343 | 335 | 82.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
