| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_203T01_9000002180_14751cztM0_level2.evt | modeM0/AS1A04_203T01_9000002180_14751cztM0_level2_quad_clean.evt |
| Size (bytes) | 668,280,960 | 70,588,800 |
| Size | 637.3 MB | 67.3 MB |
| Events in quadrant A | 10,109,613 | 401,757 |
| Events in quadrant B | 3,227,235 | 444,517 |
| Events in quadrant C | 3,500,113 | 434,854 |
| Events in quadrant D | 2,991,605 | 431,889 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 34254 | 2 |
| B | 0 | 13205 | 1 |
| C | 0 | 14052 | 1 |
| D | 0 | 12690 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6077 | 2130 | 35.050189% |
| B | 6077 | 107 | 1.760737% |
| C | 6077 | 62 | 1.020240% |
| D | 6077 | 58 | 0.954418% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7183 | 6078 | 1737 | 1737 | 24.18% | 28.58% |  |
| B | 7183 | 6078 | 11 | 11 | 0.15% | 0.18% |  |
| C | 7183 | 6078 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7183 | 6078 | 3 | 3 | 0.04% | 0.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 7239016 | 49421.52 | 728 | 714 | 146.5 |
| A | 12 | 189 | 46864 | 315.1 | 728 | 714 | 146.5 |
| A | 3 | 1 | 11789 | 75.62 | 728 | 714 | 146.5 |
| B | 4 | 142 | 65330 | 436.4 | 786 | 768 | 147.9 |
| B | 10 | 16 | 20928 | 136.27 | 786 | 768 | 147.9 |
| B | 12 | 111 | 16716 | 107.8 | 786 | 768 | 147.9 |
| C | 3 | 233 | 499997 | 2821.52 | 765 | 771 | 176.9 |
| C | 4 | 254 | 10178 | 53.17 | 765 | 771 | 176.9 |
| C | 13 | 61 | 5429 | 26.33 | 765 | 771 | 176.9 |
| D | 2 | 234 | 35737 | 185.0 | 772 | 753 | 189.1 |
| D | 2 | 120 | 24884 | 127.61 | 772 | 753 | 189.1 |
| D | 2 | 14 | 11139 | 54.92 | 772 | 753 | 189.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
