| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_081T01_9000002178_14728cztM0_level2.evt | modeM0/AS1G08_081T01_9000002178_14728cztM0_level2_quad_clean.evt |
| Size (bytes) | 833,587,200 | 162,244,800 |
| Size | 795.0 MB | 154.7 MB |
| Events in quadrant A | 6,369,691 | 1,024,437 |
| Events in quadrant B | 6,108,819 | 1,015,319 |
| Events in quadrant C | 6,058,834 | 996,576 |
| Events in quadrant D | 5,851,614 | 1,003,801 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26966 | 3 |
| B | 0 | 26483 | 2 |
| C | 0 | 25971 | 2 |
| D | 0 | 26544 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 256 | 0 |
| B | 0 | 256 | 0 |
| C | 0 | 256 | 0 |
| D | 0 | 256 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12643 | 99 | 0.783042% |
| B | 12643 | 127 | 1.004508% |
| C | 12643 | 53 | 0.419204% |
| D | 12643 | 96 | 0.759313% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 13919 | 12644 | 14 | 14 | 0.10% | 0.11% |  |
| B | 13919 | 12644 | 15 | 15 | 0.11% | 0.12% |  |
| C | 13919 | 12645 | 0 | 0 | 0.00% | 0.00% |  |
| D | 13919 | 12645 | 44 | 44 | 0.32% | 0.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 455116 | 1503.09 | 1481 | 1449 | 301.8 |
| A | 12 | 189 | 126171 | 413.23 | 1481 | 1449 | 301.8 |
| A | 15 | 69 | 35863 | 114.02 | 1481 | 1449 | 301.8 |
| B | 15 | 201 | 70974 | 244.23 | 1474 | 1436 | 284.7 |
| B | 0 | 205 | 61118 | 209.61 | 1474 | 1436 | 284.7 |
| B | 0 | 197 | 51950 | 177.41 | 1474 | 1436 | 284.7 |
| C | 3 | 233 | 471296 | 1417.39 | 1427 | 1437 | 331.5 |
| C | 13 | 61 | 10204 | 26.45 | 1427 | 1437 | 331.5 |
| C | 6 | 96 | 8866 | 22.41 | 1427 | 1437 | 331.5 |
| D | 12 | 16 | 289386 | 803.11 | 1426 | 1388 | 358.6 |
| D | 2 | 234 | 46772 | 126.56 | 1426 | 1388 | 358.6 |
| D | 15 | 0 | 38291 | 102.91 | 1426 | 1388 | 358.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
