| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C03_005T02_9000002192_14841cztM0_level2.evt | modeM0/AS1C03_005T02_9000002192_14841cztM0_level2_quad_clean.evt |
| Size (bytes) | 530,824,320 | 110,039,040 |
| Size | 506.2 MB | 104.9 MB |
| Events in quadrant A | 3,480,577 | 718,000 |
| Events in quadrant B | 3,842,886 | 704,019 |
| Events in quadrant C | 3,994,918 | 702,333 |
| Events in quadrant D | 4,251,540 | 689,588 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15361 | 2 |
| B | 0 | 16330 | 1 |
| C | 0 | 16437 | 1 |
| D | 0 | 17906 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7451 | 53 | 0.711314% |
| B | 7451 | 140 | 1.878942% |
| C | 7451 | 110 | 1.476312% |
| D | 7451 | 122 | 1.637364% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7682 | 7453 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7682 | 7452 | 37 | 37 | 0.48% | 0.50% |  |
| C | 7682 | 7453 | 60 | 60 | 0.78% | 0.81% |  |
| D | 7682 | 7453 | 78 | 78 | 1.02% | 1.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 30010 | 163.04 | 881 | 861 | 178.8 |
| A | 15 | 239 | 27253 | 147.62 | 881 | 861 | 178.8 |
| A | 3 | 1 | 22140 | 119.02 | 881 | 861 | 178.8 |
| B | 3 | 64 | 231064 | 1405.82 | 867 | 845 | 163.8 |
| B | 0 | 189 | 58137 | 349.85 | 867 | 845 | 163.8 |
| B | 0 | 219 | 46792 | 280.57 | 867 | 845 | 163.8 |
| C | 3 | 233 | 385134 | 1992.82 | 842 | 845 | 192.8 |
| C | 0 | 207 | 290457 | 1501.85 | 842 | 845 | 192.8 |
| C | 8 | 128 | 11219 | 53.8 | 842 | 845 | 192.8 |
| D | 7 | 254 | 721853 | 3185.69 | 839 | 822 | 226.3 |
| D | 7 | 38 | 124022 | 544.33 | 839 | 822 | 226.3 |
| D | 13 | 172 | 55347 | 240.9 | 839 | 822 | 226.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
