| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_054T01_9000002200_14883cztM0_level2.evt | modeM0/AS1T02_054T01_9000002200_14883cztM0_level2_quad_clean.evt |
| Size (bytes) | 601,669,440 | 94,867,200 |
| Size | 573.8 MB | 90.5 MB |
| Events in quadrant A | 3,353,199 | 623,643 |
| Events in quadrant B | 5,964,088 | 563,553 |
| Events in quadrant C | 3,401,009 | 618,788 |
| Events in quadrant D | 5,037,794 | 588,054 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14419 | 0 |
| B | 0 | 22246 | 0 |
| C | 0 | 14308 | 0 |
| D | 0 | 19978 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6863 | 117 | 1.704794% |
| B | 6864 | 1030 | 15.005828% |
| C | 6864 | 87 | 1.267483% |
| D | 6863 | 600 | 8.742532% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7293 | 6864 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7294 | 6865 | 611 | 611 | 8.38% | 8.90% |  |
| C | 7294 | 6865 | 3 | 3 | 0.04% | 0.04% |  |
| D | 7292 | 6863 | 442 | 442 | 6.06% | 6.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 237 | 79699 | 478.21 | 819 | 801 | 165.0 |
| A | 15 | 239 | 61322 | 366.82 | 819 | 801 | 165.0 |
| A | 12 | 189 | 34248 | 202.73 | 819 | 801 | 165.0 |
| B | 10 | 16 | 2643273 | 18149.24 | 769 | 750 | 145.6 |
| B | 3 | 64 | 102610 | 699.59 | 769 | 750 | 145.6 |
| B | 0 | 189 | 72940 | 495.81 | 769 | 750 | 145.6 |
| C | 3 | 233 | 233651 | 1275.75 | 792 | 794 | 182.5 |
| C | 0 | 207 | 70389 | 381.29 | 792 | 794 | 182.5 |
| C | 13 | 61 | 5820 | 27.54 | 792 | 794 | 182.5 |
| D | 7 | 254 | 1963523 | 10808.56 | 762 | 741 | 181.6 |
| D | 8 | 230 | 111161 | 608.06 | 762 | 741 | 181.6 |
| D | 2 | 120 | 29570 | 158.75 | 762 | 741 | 181.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
