| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_099T01_9000002204_14918cztM0_level2.evt | modeM0/AS1A04_099T01_9000002204_14918cztM0_level2_quad_clean.evt |
| Size (bytes) | 520,902,720 | 93,795,840 |
| Size | 496.8 MB | 89.5 MB |
| Events in quadrant A | 3,182,340 | 608,974 |
| Events in quadrant B | 5,160,756 | 599,293 |
| Events in quadrant C | 3,575,494 | 587,350 |
| Events in quadrant D | 3,400,465 | 576,046 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13810 | 3 |
| B | 0 | 19770 | 2 |
| C | 0 | 14861 | 2 |
| D | 0 | 14963 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6727 | 61 | 0.906794% |
| B | 6727 | 748 | 11.119370% |
| C | 6727 | 91 | 1.352758% |
| D | 6727 | 82 | 1.218968% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8543 | 6730 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8543 | 6730 | 499 | 499 | 5.84% | 7.41% |  |
| C | 8543 | 6730 | 24 | 24 | 0.28% | 0.36% |  |
| D | 8543 | 6730 | 19 | 19 | 0.22% | 0.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 11227 | 62.72 | 822 | 805 | 166.1 |
| A | 3 | 1 | 7764 | 41.88 | 822 | 805 | 166.1 |
| A | 0 | 226 | 7261 | 38.85 | 822 | 805 | 166.1 |
| B | 10 | 16 | 2036257 | 13189.4 | 798 | 777 | 154.3 |
| B | 12 | 111 | 18964 | 117.85 | 798 | 777 | 154.3 |
| B | 11 | 111 | 16440 | 101.49 | 798 | 777 | 154.3 |
| C | 9 | 236 | 323338 | 1749.22 | 791 | 796 | 184.4 |
| C | 3 | 233 | 169418 | 914.47 | 791 | 796 | 184.4 |
| C | 13 | 61 | 5550 | 25.78 | 791 | 796 | 184.4 |
| D | 7 | 223 | 333735 | 1764.01 | 790 | 770 | 188.8 |
| D | 13 | 104 | 42346 | 220.26 | 790 | 770 | 188.8 |
| D | 2 | 234 | 21611 | 110.41 | 790 | 770 | 188.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
