| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_056T01_9000002210_14967cztM0_level2.evt | modeM0/AS1T02_056T01_9000002210_14967cztM0_level2_quad_clean.evt |
| Size (bytes) | 480,225,600 | 90,504,000 |
| Size | 458.0 MB | 86.3 MB |
| Events in quadrant A | 3,583,260 | 590,656 |
| Events in quadrant B | 3,981,309 | 584,910 |
| Events in quadrant C | 3,351,812 | 571,384 |
| Events in quadrant D | 3,203,413 | 557,848 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14455 | 3 |
| B | 0 | 15820 | 2 |
| C | 0 | 13623 | 2 |
| D | 0 | 13387 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6248 | 137 | 2.192702% |
| B | 6248 | 248 | 3.969270% |
| C | 6248 | 89 | 1.424456% |
| D | 6248 | 102 | 1.632522% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7524 | 6249 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7524 | 6249 | 70 | 70 | 0.93% | 1.12% |  |
| C | 7524 | 6249 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7524 | 6249 | 11 | 11 | 0.15% | 0.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 106938 | 627.85 | 845 | 828 | 169.0 |
| A | 12 | 189 | 87069 | 510.29 | 845 | 828 | 169.0 |
| A | 1 | 178 | 49315 | 286.9 | 845 | 828 | 169.0 |
| B | 10 | 16 | 318588 | 2036.43 | 830 | 813 | 156.0 |
| B | 3 | 64 | 258898 | 1653.91 | 830 | 813 | 156.0 |
| B | 0 | 229 | 43888 | 276.04 | 830 | 813 | 156.0 |
| C | 3 | 233 | 139809 | 762.69 | 800 | 806 | 182.3 |
| C | 7 | 247 | 90538 | 492.35 | 800 | 806 | 182.3 |
| C | 13 | 61 | 5840 | 27.62 | 800 | 806 | 182.3 |
| D | 10 | 70 | 42835 | 213.56 | 812 | 791 | 196.9 |
| D | 7 | 223 | 29817 | 147.44 | 812 | 791 | 196.9 |
| D | 2 | 234 | 22357 | 109.54 | 812 | 791 | 196.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
