| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_056T01_9000002210_14976cztM0_level2.evt | modeM0/AS1T02_056T01_9000002210_14976cztM0_level2_quad_clean.evt |
| Size (bytes) | 467,262,720 | 81,809,280 |
| Size | 445.6 MB | 78.0 MB |
| Events in quadrant A | 3,255,797 | 515,109 |
| Events in quadrant B | 3,620,603 | 516,688 |
| Events in quadrant C | 3,168,568 | 503,993 |
| Events in quadrant D | 3,659,190 | 483,036 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13826 | 3 |
| B | 0 | 14986 | 2 |
| C | 0 | 13493 | 2 |
| D | 0 | 15385 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6573 | 29 | 0.441199% |
| B | 6573 | 120 | 1.825650% |
| C | 6573 | 18 | 0.273848% |
| D | 6573 | 191 | 2.905827% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7599 | 6575 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7598 | 6574 | 62 | 62 | 0.82% | 0.94% |  |
| C | 7599 | 6575 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7599 | 6575 | 160 | 160 | 2.11% | 2.43% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 61684 | 379.6 | 787 | 770 | 160.5 |
| A | 12 | 189 | 53208 | 326.78 | 787 | 770 | 160.5 |
| A | 15 | 157 | 32203 | 195.88 | 787 | 770 | 160.5 |
| B | 3 | 64 | 349260 | 2325.53 | 785 | 766 | 149.9 |
| B | 0 | 219 | 46093 | 302.47 | 785 | 766 | 149.9 |
| B | 10 | 245 | 42333 | 277.38 | 785 | 766 | 149.9 |
| C | 3 | 233 | 171080 | 952.42 | 766 | 770 | 178.8 |
| C | 8 | 128 | 7031 | 35.01 | 766 | 770 | 178.8 |
| C | 13 | 61 | 5469 | 26.28 | 766 | 770 | 178.8 |
| D | 13 | 249 | 359979 | 1818.12 | 747 | 728 | 197.6 |
| D | 7 | 223 | 352661 | 1781.08 | 747 | 728 | 197.6 |
| D | 2 | 234 | 25208 | 123.89 | 747 | 728 | 197.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
