| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_218T03_9000002214_15033cztM0_level2.evt | modeM0/AS1A04_218T03_9000002214_15033cztM0_level2_quad_clean.evt |
| Size (bytes) | 529,142,400 | 94,619,520 |
| Size | 504.6 MB | 90.2 MB |
| Events in quadrant A | 3,857,426 | 599,819 |
| Events in quadrant B | 3,999,608 | 598,616 |
| Events in quadrant C | 3,877,631 | 593,198 |
| Events in quadrant D | 3,800,598 | 570,945 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16148 | 3 |
| B | 0 | 16403 | 2 |
| C | 0 | 15675 | 2 |
| D | 0 | 16070 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7215 | 92 | 1.275121% |
| B | 7215 | 175 | 2.425502% |
| C | 7215 | 57 | 0.790021% |
| D | 7215 | 95 | 1.316701% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8882 | 7218 | 3 | 3 | 0.03% | 0.04% |  |
| B | 8882 | 7217 | 70 | 70 | 0.79% | 0.97% |  |
| C | 8882 | 7217 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8882 | 7216 | 28 | 28 | 0.32% | 0.39% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 122190 | 677.08 | 881 | 861 | 179.2 |
| A | 12 | 189 | 106114 | 587.36 | 881 | 861 | 179.2 |
| A | 15 | 239 | 68470 | 377.29 | 881 | 861 | 179.2 |
| B | 10 | 16 | 340405 | 1986.23 | 881 | 857 | 171.0 |
| B | 3 | 64 | 64296 | 371.09 | 881 | 857 | 171.0 |
| B | 0 | 229 | 54507 | 313.83 | 881 | 857 | 171.0 |
| C | 3 | 233 | 511935 | 2533.57 | 862 | 865 | 201.7 |
| C | 13 | 61 | 6190 | 26.4 | 862 | 865 | 201.7 |
| C | 3 | 232 | 4617 | 18.6 | 862 | 865 | 201.7 |
| D | 2 | 136 | 263824 | 1251.31 | 858 | 831 | 210.2 |
| D | 12 | 235 | 125782 | 594.51 | 858 | 831 | 210.2 |
| D | 13 | 172 | 40511 | 188.8 | 858 | 831 | 210.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
