| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_028T01_9000002220_15100cztM0_level2.evt | modeM0/AS1G08_028T01_9000002220_15100cztM0_level2_quad_clean.evt |
| Size (bytes) | 541,131,840 | 88,796,160 |
| Size | 516.1 MB | 84.7 MB |
| Events in quadrant A | 3,808,328 | 543,358 |
| Events in quadrant B | 4,241,185 | 550,863 |
| Events in quadrant C | 4,151,265 | 539,726 |
| Events in quadrant D | 3,665,089 | 519,702 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16278 | 4 |
| B | 0 | 17435 | 3 |
| C | 0 | 16759 | 3 |
| D | 0 | 16426 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7697 | 298 | 3.871638% |
| B | 7697 | 337 | 4.378329% |
| C | 7697 | 248 | 3.222035% |
| D | 7697 | 234 | 3.040146% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8828 | 7697 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8828 | 7697 | 2 | 2 | 0.02% | 0.03% |  |
| C | 8828 | 7698 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8828 | 7698 | 9 | 9 | 0.10% | 0.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 47047 | 232.5 | 978 | 958 | 198.2 |
| A | 0 | 226 | 8504 | 38.07 | 978 | 958 | 198.2 |
| A | 12 | 194 | 7199 | 31.48 | 978 | 958 | 198.2 |
| B | 3 | 64 | 353874 | 1830.66 | 969 | 940 | 192.8 |
| B | 10 | 245 | 89496 | 459.34 | 969 | 940 | 192.8 |
| B | 12 | 111 | 24100 | 120.13 | 969 | 940 | 192.8 |
| C | 3 | 233 | 400005 | 1796.01 | 946 | 950 | 222.2 |
| C | 3 | 9 | 63907 | 283.35 | 946 | 950 | 222.2 |
| C | 13 | 61 | 6718 | 25.96 | 946 | 950 | 222.2 |
| D | 10 | 70 | 74509 | 315.61 | 948 | 919 | 233.2 |
| D | 2 | 234 | 29024 | 120.54 | 948 | 919 | 233.2 |
| D | 13 | 104 | 17703 | 71.98 | 948 | 919 | 233.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
