| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_130T03_9000002224_15113cztM0_level2.evt | modeM0/AS1A04_130T03_9000002224_15113cztM0_level2_quad_clean.evt |
| Size (bytes) | 517,746,240 | 94,993,920 |
| Size | 493.8 MB | 90.6 MB |
| Events in quadrant A | 3,243,338 | 611,958 |
| Events in quadrant B | 4,654,683 | 606,702 |
| Events in quadrant C | 3,872,791 | 611,502 |
| Events in quadrant D | 3,459,791 | 584,896 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13672 | 3 |
| B | 0 | 17959 | 2 |
| C | 0 | 15344 | 2 |
| D | 0 | 14538 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6623 | 91 | 1.374000% |
| B | 6623 | 506 | 7.640042% |
| C | 6623 | 129 | 1.947758% |
| D | 6623 | 103 | 1.555186% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7609 | 6624 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7609 | 6625 | 322 | 322 | 4.23% | 4.86% |  |
| C | 7609 | 6624 | 47 | 47 | 0.62% | 0.71% |  |
| D | 7609 | 6625 | 25 | 25 | 0.33% | 0.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 21740 | 124.57 | 836 | 819 | 168.0 |
| A | 0 | 226 | 7438 | 39.41 | 836 | 819 | 168.0 |
| A | 12 | 189 | 6729 | 35.19 | 836 | 819 | 168.0 |
| B | 10 | 245 | 1044349 | 6761.65 | 804 | 782 | 154.3 |
| B | 3 | 64 | 415489 | 2687.04 | 804 | 782 | 154.3 |
| B | 12 | 111 | 17830 | 110.46 | 804 | 782 | 154.3 |
| C | 3 | 233 | 365986 | 1958.92 | 815 | 820 | 186.4 |
| C | 4 | 254 | 328428 | 1757.44 | 815 | 820 | 186.4 |
| C | 13 | 61 | 5699 | 26.17 | 815 | 820 | 186.4 |
| D | 2 | 14 | 173025 | 859.27 | 822 | 798 | 200.4 |
| D | 1 | 255 | 44056 | 215.82 | 822 | 798 | 200.4 |
| D | 7 | 223 | 31711 | 154.23 | 822 | 798 | 200.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
