| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_218T03_9000002232_15138cztM0_level2.evt | modeM0/AS1A04_218T03_9000002232_15138cztM0_level2_quad_clean.evt |
| Size (bytes) | 438,082,560 | 105,690,240 |
| Size | 417.8 MB | 100.8 MB |
| Events in quadrant A | 3,231,722 | 689,287 |
| Events in quadrant B | 3,222,036 | 712,599 |
| Events in quadrant C | 3,199,661 | 700,603 |
| Events in quadrant D | 3,191,034 | 663,991 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13642 | 3 |
| B | 0 | 13575 | 2 |
| C | 0 | 13391 | 2 |
| D | 0 | 13608 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6226 | 29 | 0.465789% |
| B | 6226 | 38 | 0.610344% |
| C | 6226 | 18 | 0.289110% |
| D | 6226 | 48 | 0.770960% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7497 | 6228 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7497 | 6228 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7497 | 6228 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7497 | 6228 | 29 | 29 | 0.39% | 0.47% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 117616 | 724.86 | 797 | 782 | 161.2 |
| A | 1 | 162 | 26300 | 158.32 | 797 | 782 | 161.2 |
| A | 1 | 178 | 8230 | 46.21 | 797 | 782 | 161.2 |
| B | 12 | 111 | 17479 | 109.97 | 807 | 789 | 151.8 |
| B | 0 | 230 | 16273 | 102.03 | 807 | 789 | 151.8 |
| B | 3 | 64 | 14896 | 92.95 | 807 | 789 | 151.8 |
| C | 3 | 233 | 109767 | 595.18 | 793 | 799 | 183.1 |
| C | 13 | 61 | 5660 | 26.55 | 793 | 799 | 183.1 |
| C | 3 | 202 | 1790 | 5.41 | 793 | 799 | 183.1 |
| D | 0 | 11 | 86691 | 453.39 | 783 | 761 | 189.5 |
| D | 13 | 172 | 66721 | 348.03 | 783 | 761 | 189.5 |
| D | 2 | 16 | 27427 | 140.7 | 783 | 761 | 189.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
