| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_105T01_9000002248_15227cztM0_level2.evt | modeM0/AS1A04_105T01_9000002248_15227cztM0_level2_quad_clean.evt |
| Size (bytes) | 563,578,560 | 87,912,000 |
| Size | 537.5 MB | 83.8 MB |
| Events in quadrant A | 3,978,101 | 587,592 |
| Events in quadrant B | 3,410,342 | 609,596 |
| Events in quadrant C | 6,161,927 | 482,507 |
| Events in quadrant D | 3,105,195 | 557,063 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15940 | 3 |
| B | 0 | 13955 | 2 |
| C | 0 | 22626 | 2 |
| D | 0 | 13319 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6088 | 80 | 1.314060% |
| B | 6088 | 71 | 1.166229% |
| C | 6088 | 1098 | 18.035480% |
| D | 6088 | 43 | 0.706307% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7469 | 6090 | 89 | 89 | 1.19% | 1.46% |  |
| B | 7469 | 6090 | 28 | 28 | 0.37% | 0.46% |  |
| C | 7469 | 6090 | 969 | 969 | 12.97% | 15.91% |  |
| D | 7469 | 6090 | 29 | 29 | 0.39% | 0.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 253 | 825328 | 5228.73 | 782 | 768 | 157.7 |
| A | 12 | 189 | 105079 | 661.46 | 782 | 768 | 157.7 |
| A | 9 | 143 | 29363 | 181.33 | 782 | 768 | 157.7 |
| B | 3 | 64 | 160597 | 1097.58 | 788 | 772 | 145.6 |
| B | 0 | 190 | 56040 | 379.55 | 788 | 772 | 145.6 |
| B | 0 | 189 | 40219 | 270.9 | 788 | 772 | 145.6 |
| C | 3 | 233 | 3415993 | 22237.1 | 665 | 670 | 153.6 |
| C | 4 | 254 | 129571 | 839.27 | 665 | 670 | 153.6 |
| C | 7 | 247 | 18940 | 118.96 | 665 | 670 | 153.6 |
| D | 7 | 38 | 145411 | 789.02 | 749 | 728 | 183.4 |
| D | 2 | 16 | 69308 | 374.0 | 749 | 728 | 183.4 |
| D | 13 | 172 | 31988 | 170.47 | 749 | 728 | 183.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
