| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_207T01_9000002254_15274cztM0_level2.evt | modeM0/AS1A04_207T01_9000002254_15274cztM0_level2_quad_clean.evt |
| Size (bytes) | 550,327,680 | 105,266,880 |
| Size | 524.8 MB | 100.4 MB |
| Events in quadrant A | 3,831,627 | 668,013 |
| Events in quadrant B | 4,281,093 | 673,821 |
| Events in quadrant C | 4,074,866 | 670,232 |
| Events in quadrant D | 3,954,083 | 637,962 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 160 | 0 |
| B | 0 | 160 | 0 |
| C | 0 | 160 | 0 |
| D | 0 | 160 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16535 | 3 |
| B | 0 | 17603 | 2 |
| C | 0 | 16981 | 2 |
| D | 0 | 17154 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7732 | 64 | 0.827729% |
| B | 7732 | 200 | 2.586653% |
| C | 7732 | 54 | 0.698396% |
| D | 7732 | 118 | 1.526125% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8983 | 7735 | 9 | 9 | 0.10% | 0.12% |  |
| B | 8983 | 7735 | 90 | 90 | 1.00% | 1.16% |  |
| C | 8983 | 7735 | 2 | 2 | 0.02% | 0.03% |  |
| D | 8983 | 7735 | 64 | 64 | 0.71% | 0.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 159478 | 824.24 | 933 | 913 | 192.4 |
| A | 4 | 2 | 49518 | 252.66 | 933 | 913 | 192.4 |
| A | 9 | 143 | 35283 | 178.66 | 933 | 913 | 192.4 |
| B | 10 | 16 | 191406 | 1075.48 | 931 | 907 | 177.1 |
| B | 0 | 229 | 111702 | 625.5 | 931 | 907 | 177.1 |
| B | 0 | 219 | 108292 | 606.25 | 931 | 907 | 177.1 |
| C | 3 | 233 | 466715 | 2194.59 | 905 | 911 | 212.3 |
| C | 4 | 254 | 73979 | 344.25 | 905 | 911 | 212.3 |
| C | 13 | 61 | 6580 | 26.71 | 905 | 911 | 212.3 |
| D | 2 | 33 | 304591 | 1379.53 | 899 | 872 | 220.2 |
| D | 7 | 38 | 120579 | 543.72 | 899 | 872 | 220.2 |
| D | 5 | 222 | 46108 | 205.47 | 899 | 872 | 220.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
