| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_073T01_9000002260_15328cztM0_level2.evt | modeM0/AS1T02_073T01_9000002260_15328cztM0_level2_quad_clean.evt |
| Size (bytes) | 463,849,920 | 106,511,040 |
| Size | 442.4 MB | 101.6 MB |
| Events in quadrant A | 2,900,148 | 714,840 |
| Events in quadrant B | 3,111,141 | 728,751 |
| Events in quadrant C | 3,005,474 | 722,067 |
| Events in quadrant D | 4,640,158 | 657,638 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12270 | 2 |
| B | 0 | 12882 | 1 |
| C | 0 | 12482 | 1 |
| D | 0 | 17445 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5753 | 59 | 1.025552% |
| B | 5753 | 82 | 1.425343% |
| C | 5753 | 57 | 0.990787% |
| D | 5753 | 595 | 10.342430% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7079 | 5755 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7079 | 5755 | 7 | 7 | 0.10% | 0.12% |  |
| C | 7079 | 5755 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7079 | 5755 | 398 | 398 | 5.62% | 6.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 6660 | 39.66 | 753 | 739 | 149.3 |
| A | 12 | 194 | 5440 | 31.49 | 753 | 739 | 149.3 |
| A | 3 | 137 | 4927 | 28.05 | 753 | 739 | 149.3 |
| B | 4 | 173 | 144912 | 1023.78 | 752 | 734 | 140.8 |
| B | 4 | 48 | 17097 | 116.19 | 752 | 734 | 140.8 |
| B | 12 | 111 | 16290 | 110.46 | 752 | 734 | 140.8 |
| C | 3 | 233 | 91636 | 531.29 | 747 | 753 | 171.1 |
| C | 13 | 61 | 5258 | 26.34 | 747 | 753 | 171.1 |
| C | 8 | 222 | 1790 | 6.06 | 747 | 753 | 171.1 |
| D | 13 | 122 | 1288405 | 7413.97 | 722 | 705 | 173.7 |
| D | 2 | 33 | 338028 | 1942.15 | 722 | 705 | 173.7 |
| D | 1 | 52 | 167647 | 961.17 | 722 | 705 | 173.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
