| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_037T01_9000002264_15367cztM0_level2.evt | modeM0/AS1G08_037T01_9000002264_15367cztM0_level2_quad_clean.evt |
| Size (bytes) | 474,477,120 | 76,567,680 |
| Size | 452.5 MB | 73.0 MB |
| Events in quadrant A | 3,222,846 | 471,316 |
| Events in quadrant B | 3,456,204 | 476,881 |
| Events in quadrant C | 3,599,540 | 466,089 |
| Events in quadrant D | 3,641,527 | 442,654 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13707 | 3 |
| B | 0 | 14273 | 2 |
| C | 0 | 14655 | 2 |
| D | 0 | 15248 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6620 | 61 | 0.921450% |
| B | 6620 | 95 | 1.435045% |
| C | 6620 | 55 | 0.830816% |
| D | 6620 | 149 | 2.250755% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7651 | 6621 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7651 | 6621 | 9 | 9 | 0.12% | 0.14% |  |
| C | 7651 | 6621 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7651 | 6621 | 83 | 83 | 1.08% | 1.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 14481 | 81.13 | 832 | 815 | 168.5 |
| A | 0 | 226 | 7512 | 39.76 | 832 | 815 | 168.5 |
| A | 12 | 194 | 6138 | 31.6 | 832 | 815 | 168.5 |
| B | 10 | 245 | 61646 | 382.56 | 831 | 810 | 159.0 |
| B | 6 | 36 | 46416 | 286.79 | 831 | 810 | 159.0 |
| B | 0 | 229 | 39382 | 242.55 | 831 | 810 | 159.0 |
| C | 3 | 233 | 458957 | 2478.81 | 804 | 811 | 184.8 |
| C | 13 | 61 | 5767 | 26.81 | 804 | 811 | 184.8 |
| C | 5 | 96 | 5518 | 25.47 | 804 | 811 | 184.8 |
| D | 2 | 33 | 240514 | 1227.25 | 799 | 775 | 195.3 |
| D | 10 | 70 | 139098 | 708.09 | 799 | 775 | 195.3 |
| D | 9 | 68 | 116801 | 593.95 | 799 | 775 | 195.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
