| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C03_001T01_9000002270_15385cztM0_level2.evt | modeM0/AS1C03_001T01_9000002270_15385cztM0_level2_quad_clean.evt |
| Size (bytes) | 498,052,800 | 109,486,080 |
| Size | 475.0 MB | 104.4 MB |
| Events in quadrant A | 3,127,878 | 749,827 |
| Events in quadrant B | 4,172,534 | 727,927 |
| Events in quadrant C | 3,291,425 | 734,561 |
| Events in quadrant D | 4,101,221 | 701,037 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13089 | 2 |
| B | 0 | 16270 | 1 |
| C | 0 | 13208 | 1 |
| D | 0 | 16056 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5756 | 113 | 1.963169% |
| B | 5756 | 291 | 5.055594% |
| C | 5756 | 66 | 1.146630% |
| D | 5756 | 244 | 4.239055% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7012 | 5757 | 25 | 25 | 0.36% | 0.43% |  |
| B | 7012 | 5758 | 162 | 162 | 2.31% | 2.81% |  |
| C | 7012 | 5757 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7012 | 5757 | 207 | 207 | 2.95% | 3.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 219277 | 1508.75 | 729 | 716 | 144.9 |
| A | 14 | 237 | 65600 | 447.9 | 729 | 716 | 144.9 |
| A | 9 | 143 | 26198 | 175.91 | 729 | 716 | 144.9 |
| B | 10 | 16 | 529436 | 4028.34 | 713 | 698 | 131.3 |
| B | 10 | 245 | 246514 | 1872.82 | 713 | 698 | 131.3 |
| B | 7 | 220 | 151599 | 1149.68 | 713 | 698 | 131.3 |
| C | 3 | 233 | 530270 | 3314.82 | 706 | 711 | 159.8 |
| C | 13 | 61 | 5033 | 27.05 | 706 | 711 | 159.8 |
| C | 0 | 207 | 4875 | 26.06 | 706 | 711 | 159.8 |
| D | 13 | 122 | 806458 | 4687.86 | 710 | 689 | 171.9 |
| D | 7 | 38 | 229426 | 1330.76 | 710 | 689 | 171.9 |
| D | 5 | 222 | 120008 | 694.18 | 710 | 689 | 171.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
