| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_072T01_9000002272_15398cztM0_level2.evt | modeM0/AS1G08_072T01_9000002272_15398cztM0_level2_quad_clean.evt |
| Size (bytes) | 322,928,640 | 37,310,400 |
| Size | 308.0 MB | 35.6 MB |
| Events in quadrant A | 1,546,257 | 240,980 |
| Events in quadrant B | 1,685,254 | 241,761 |
| Events in quadrant C | 1,660,134 | 240,523 |
| Events in quadrant D | 4,684,360 | 193,175 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 62 | 0 |
| B | 0 | 62 | 0 |
| C | 0 | 62 | 0 |
| D | 0 | 62 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6567 | 2 |
| B | 0 | 6889 | 1 |
| C | 0 | 6967 | 1 |
| D | 0 | 15942 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2975 | 54 | 1.815126% |
| B | 2975 | 73 | 2.453782% |
| C | 2975 | 52 | 1.747899% |
| D | 2975 | 1360 | 45.714286% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4151 | 2976 | 1 | 1 | 0.02% | 0.03% |  |
| B | 4151 | 2976 | 6 | 6 | 0.14% | 0.20% |  |
| C | 4151 | 2976 | 0 | 0 | 0.00% | 0.00% |  |
| D | 4150 | 2975 | 1123 | 1123 | 27.06% | 37.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 18364 | 221.78 | 395 | 388 | 81.1 |
| A | 12 | 96 | 4326 | 48.58 | 395 | 388 | 81.1 |
| A | 15 | 157 | 3600 | 39.63 | 395 | 388 | 81.1 |
| B | 10 | 16 | 27979 | 364.34 | 394 | 385 | 75.7 |
| B | 0 | 229 | 22418 | 290.92 | 394 | 385 | 75.7 |
| B | 0 | 189 | 16433 | 211.89 | 394 | 385 | 75.7 |
| C | 3 | 233 | 132657 | 1490.54 | 383 | 386 | 88.7 |
| C | 7 | 247 | 19176 | 211.74 | 383 | 386 | 88.7 |
| C | 10 | 22 | 11505 | 125.3 | 383 | 386 | 88.7 |
| D | 13 | 122 | 2739899 | 35614.31 | 312 | 303 | 76.9 |
| D | 5 | 222 | 393856 | 5116.13 | 312 | 303 | 76.9 |
| D | 9 | 68 | 143253 | 1858.33 | 312 | 303 | 76.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
