| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_072T01_9000002272_15400cztM0_level2.evt | modeM0/AS1G08_072T01_9000002272_15400cztM0_level2_quad_clean.evt |
| Size (bytes) | 631,912,320 | 100,834,560 |
| Size | 602.6 MB | 96.2 MB |
| Events in quadrant A | 3,220,564 | 696,979 |
| Events in quadrant B | 3,621,632 | 703,978 |
| Events in quadrant C | 3,294,171 | 692,884 |
| Events in quadrant D | 8,590,364 | 535,271 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13454 | 2 |
| B | 0 | 14768 | 1 |
| C | 0 | 13565 | 1 |
| D | 0 | 29851 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6070 | 111 | 1.828666% |
| B | 6070 | 131 | 2.158155% |
| C | 6070 | 90 | 1.482702% |
| D | 6070 | 1895 | 31.219110% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7341 | 6071 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7341 | 6071 | 22 | 22 | 0.30% | 0.36% |  |
| C | 7341 | 6071 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7341 | 6071 | 1440 | 1440 | 19.62% | 23.72% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 18281 | 105.53 | 824 | 811 | 165.5 |
| A | 9 | 143 | 14221 | 81.0 | 824 | 811 | 165.5 |
| A | 14 | 238 | 10922 | 61.08 | 824 | 811 | 165.5 |
| B | 10 | 16 | 137980 | 898.0 | 817 | 800 | 152.8 |
| B | 8 | 3 | 84874 | 550.36 | 817 | 800 | 152.8 |
| B | 0 | 197 | 52269 | 336.92 | 817 | 800 | 152.8 |
| C | 3 | 233 | 168411 | 935.58 | 787 | 791 | 179.2 |
| C | 7 | 247 | 49939 | 274.32 | 787 | 791 | 179.2 |
| C | 10 | 22 | 6411 | 31.37 | 787 | 791 | 179.2 |
| D | 13 | 122 | 4782437 | 29218.31 | 684 | 665 | 163.7 |
| D | 2 | 33 | 563682 | 3440.23 | 684 | 665 | 163.7 |
| D | 9 | 68 | 484815 | 2958.33 | 684 | 665 | 163.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
