| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_072T01_9000002272_15410cztM0_level2.evt | modeM0/AS1G08_072T01_9000002272_15410cztM0_level2_quad_clean.evt |
| Size (bytes) | 540,786,240 | 65,773,440 |
| Size | 515.7 MB | 62.7 MB |
| Events in quadrant A | 3,231,989 | 390,069 |
| Events in quadrant B | 3,407,222 | 398,890 |
| Events in quadrant C | 4,852,450 | 377,270 |
| Events in quadrant D | 4,441,251 | 367,352 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13884 | 3 |
| B | 0 | 14121 | 2 |
| C | 0 | 18899 | 2 |
| D | 0 | 17475 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6566 | 57 | 0.868108% |
| B | 6566 | 61 | 0.929028% |
| C | 6566 | 331 | 5.041121% |
| D | 6566 | 263 | 4.005483% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7572 | 6568 | 15 | 15 | 0.20% | 0.23% |  |
| B | 7572 | 6568 | 8 | 8 | 0.11% | 0.12% |  |
| C | 7572 | 6567 | 234 | 234 | 3.09% | 3.56% |  |
| D | 7572 | 6568 | 205 | 205 | 2.71% | 3.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 102945 | 634.39 | 796 | 780 | 161.0 |
| A | 14 | 237 | 34710 | 210.69 | 796 | 780 | 161.0 |
| A | 9 | 143 | 21561 | 129.04 | 796 | 780 | 161.0 |
| B | 0 | 189 | 70221 | 450.56 | 804 | 783 | 154.1 |
| B | 0 | 197 | 67531 | 433.11 | 804 | 783 | 154.1 |
| B | 10 | 245 | 58582 | 375.04 | 804 | 783 | 154.1 |
| C | 3 | 233 | 1823851 | 10259.08 | 767 | 771 | 177.7 |
| C | 7 | 247 | 29547 | 161.93 | 767 | 771 | 177.7 |
| C | 13 | 61 | 5613 | 27.25 | 767 | 771 | 177.7 |
| D | 13 | 122 | 743209 | 3948.88 | 767 | 744 | 188.0 |
| D | 5 | 222 | 445026 | 2362.96 | 767 | 744 | 188.0 |
| D | 1 | 52 | 137146 | 725.47 | 767 | 744 | 188.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
