| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T02_080T01_9000002276_15428cztM0_level2.evt | modeM0/AS1T02_080T01_9000002276_15428cztM0_level2_quad_clean.evt |
| Size (bytes) | 701,104,320 | 89,455,680 |
| Size | 668.6 MB | 85.3 MB |
| Events in quadrant A | 3,707,598 | 583,441 |
| Events in quadrant B | 3,576,949 | 594,793 |
| Events in quadrant C | 5,207,928 | 583,028 |
| Events in quadrant D | 8,305,471 | 497,730 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15182 | 3 |
| B | 0 | 14624 | 2 |
| C | 0 | 20328 | 2 |
| D | 0 | 28901 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6442 | 167 | 2.592363% |
| B | 6442 | 143 | 2.219808% |
| C | 6442 | 192 | 2.980441% |
| D | 6442 | 1868 | 28.997206% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8893 | 6443 | 17 | 17 | 0.19% | 0.26% |  |
| B | 8893 | 6443 | 6 | 6 | 0.07% | 0.09% |  |
| C | 8893 | 6443 | 23 | 23 | 0.26% | 0.36% |  |
| D | 8893 | 6443 | 1524 | 1524 | 17.14% | 23.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 193250 | 1099.7 | 884 | 867 | 174.9 |
| A | 14 | 237 | 92158 | 521.84 | 884 | 867 | 174.9 |
| A | 9 | 143 | 18426 | 100.37 | 884 | 867 | 174.9 |
| B | 0 | 189 | 30732 | 181.4 | 880 | 859 | 164.7 |
| B | 0 | 197 | 29449 | 173.61 | 880 | 859 | 164.7 |
| B | 0 | 213 | 21053 | 122.62 | 880 | 859 | 164.7 |
| C | 3 | 233 | 1808072 | 9406.78 | 852 | 858 | 192.1 |
| C | 7 | 247 | 58055 | 297.72 | 852 | 858 | 192.1 |
| C | 14 | 234 | 12186 | 58.96 | 852 | 858 | 192.1 |
| D | 5 | 222 | 4808483 | 25215.73 | 793 | 771 | 190.7 |
| D | 13 | 122 | 268608 | 1404.76 | 793 | 771 | 190.7 |
| D | 7 | 38 | 56595 | 292.79 | 793 | 771 | 190.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
