| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_203T01_9000002284_15459cztM0_level2.evt | modeM0/AS1A04_203T01_9000002284_15459cztM0_level2_quad_clean.evt |
| Size (bytes) | 526,201,920 | 67,109,760 |
| Size | 501.8 MB | 64.0 MB |
| Events in quadrant A | 4,075,138 | 402,309 |
| Events in quadrant B | 3,684,431 | 405,477 |
| Events in quadrant C | 3,626,685 | 398,246 |
| Events in quadrant D | 4,116,638 | 379,839 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16218 | 3 |
| B | 0 | 14984 | 2 |
| C | 0 | 14591 | 2 |
| D | 0 | 16313 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6389 | 235 | 3.678197% |
| B | 6389 | 145 | 2.269526% |
| C | 6389 | 88 | 1.377367% |
| D | 6389 | 296 | 4.632963% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7700 | 6390 | 47 | 47 | 0.61% | 0.74% |  |
| B | 7700 | 6390 | 5 | 5 | 0.06% | 0.08% |  |
| C | 7700 | 6390 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7700 | 6390 | 151 | 151 | 1.96% | 2.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 375136 | 2082.77 | 894 | 878 | 179.7 |
| A | 14 | 237 | 145585 | 805.3 | 894 | 878 | 179.7 |
| A | 13 | 248 | 55608 | 304.58 | 894 | 878 | 179.7 |
| B | 3 | 209 | 39726 | 234.29 | 887 | 869 | 165.8 |
| B | 0 | 197 | 37091 | 218.4 | 887 | 869 | 165.8 |
| B | 0 | 229 | 36875 | 217.1 | 887 | 869 | 165.8 |
| C | 3 | 233 | 243801 | 1235.33 | 863 | 871 | 196.7 |
| C | 9 | 54 | 10724 | 50.1 | 863 | 871 | 196.7 |
| C | 13 | 61 | 6288 | 27.55 | 863 | 871 | 196.7 |
| D | 2 | 33 | 343899 | 1624.36 | 867 | 843 | 211.2 |
| D | 5 | 222 | 222672 | 1050.36 | 867 | 843 | 211.2 |
| D | 7 | 38 | 91053 | 427.14 | 867 | 843 | 211.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
