| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_203T01_9000002284_15470cztM0_level2.evt | modeM0/AS1A04_203T01_9000002284_15470cztM0_level2_quad_clean.evt |
| Size (bytes) | 532,131,840 | 80,352,000 |
| Size | 507.5 MB | 76.6 MB |
| Events in quadrant A | 3,076,378 | 511,268 |
| Events in quadrant B | 3,164,080 | 516,034 |
| Events in quadrant C | 3,054,627 | 501,359 |
| Events in quadrant D | 6,396,626 | 467,636 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12920 | 2 |
| B | 0 | 13069 | 1 |
| C | 0 | 12899 | 1 |
| D | 0 | 23269 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6255 | 59 | 0.943245% |
| B | 6255 | 74 | 1.183054% |
| C | 6255 | 46 | 0.735412% |
| D | 6255 | 421 | 6.730616% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7381 | 6256 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7381 | 6256 | 5 | 5 | 0.07% | 0.08% |  |
| C | 7381 | 6256 | 4 | 4 | 0.05% | 0.06% |  |
| D | 7381 | 6256 | 360 | 360 | 4.88% | 5.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 9496 | 54.05 | 798 | 780 | 161.2 |
| A | 0 | 226 | 7171 | 39.64 | 798 | 780 | 161.2 |
| A | 12 | 194 | 5920 | 31.88 | 798 | 780 | 161.2 |
| B | 0 | 213 | 24427 | 157.46 | 786 | 770 | 150.2 |
| B | 3 | 209 | 21002 | 134.66 | 786 | 770 | 150.2 |
| B | 0 | 189 | 19674 | 125.82 | 786 | 770 | 150.2 |
| C | 3 | 233 | 67998 | 382.96 | 759 | 764 | 175.6 |
| C | 14 | 225 | 18995 | 103.84 | 759 | 764 | 175.6 |
| C | 0 | 207 | 5576 | 27.41 | 759 | 764 | 175.6 |
| D | 1 | 52 | 3199339 | 17056.52 | 760 | 738 | 187.5 |
| D | 2 | 33 | 143437 | 760.94 | 760 | 738 | 187.5 |
| D | 5 | 222 | 139578 | 740.36 | 760 | 738 | 187.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
