| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_030T01_9000002302_15554cztM0_level2.evt | modeM0/AS1G08_030T01_9000002302_15554cztM0_level2_quad_clean.evt |
| Size (bytes) | 452,079,360 | 97,922,880 |
| Size | 431.1 MB | 93.4 MB |
| Events in quadrant A | 3,198,218 | 632,968 |
| Events in quadrant B | 3,514,195 | 635,575 |
| Events in quadrant C | 3,293,903 | 608,657 |
| Events in quadrant D | 3,208,740 | 600,489 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14255 | 3 |
| B | 0 | 15030 | 2 |
| C | 0 | 14380 | 2 |
| D | 0 | 14509 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7005 | 30 | 0.428266% |
| B | 7005 | 86 | 1.227695% |
| C | 7005 | 60 | 0.856531% |
| D | 7005 | 47 | 0.670949% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8631 | 7008 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8631 | 7008 | 28 | 28 | 0.32% | 0.40% |  |
| C | 8631 | 7007 | 1 | 1 | 0.01% | 0.01% |  |
| D | 8631 | 7008 | 23 | 23 | 0.27% | 0.33% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7163 | 37.63 | 831 | 814 | 168.7 |
| A | 12 | 194 | 6148 | 31.62 | 831 | 814 | 168.7 |
| A | 3 | 137 | 5674 | 28.81 | 831 | 814 | 168.7 |
| B | 3 | 64 | 212402 | 1326.34 | 830 | 810 | 159.5 |
| B | 0 | 214 | 31799 | 194.25 | 830 | 810 | 159.5 |
| B | 12 | 111 | 18980 | 113.9 | 830 | 810 | 159.5 |
| C | 14 | 238 | 124144 | 657.29 | 801 | 806 | 187.6 |
| C | 3 | 233 | 30351 | 157.45 | 801 | 806 | 187.6 |
| C | 10 | 22 | 9063 | 44.0 | 801 | 806 | 187.6 |
| D | 15 | 0 | 72118 | 324.83 | 800 | 783 | 219.6 |
| D | 2 | 234 | 28303 | 125.31 | 800 | 783 | 219.6 |
| D | 5 | 51 | 19735 | 86.3 | 800 | 783 | 219.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
