| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_198T01_9000002308_15573cztM0_level2.evt | modeM0/AS1A04_198T01_9000002308_15573cztM0_level2_quad_clean.evt |
| Size (bytes) | 529,067,520 | 97,977,600 |
| Size | 504.6 MB | 93.4 MB |
| Events in quadrant A | 3,166,533 | 643,995 |
| Events in quadrant B | 3,296,296 | 651,644 |
| Events in quadrant C | 3,258,357 | 634,412 |
| Events in quadrant D | 5,885,170 | 608,484 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13073 | 3 |
| B | 0 | 13489 | 2 |
| C | 0 | 13339 | 2 |
| D | 0 | 21506 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6135 | 42 | 0.684597% |
| B | 6135 | 74 | 1.206194% |
| C | 6135 | 79 | 1.287694% |
| D | 6135 | 1005 | 16.381418% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7451 | 6136 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7451 | 6136 | 6 | 6 | 0.08% | 0.10% |  |
| C | 7451 | 6136 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7451 | 6136 | 837 | 837 | 11.23% | 13.64% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 30741 | 184.16 | 815 | 797 | 162.6 |
| A | 0 | 226 | 7516 | 41.32 | 815 | 797 | 162.6 |
| A | 12 | 194 | 6188 | 33.16 | 815 | 797 | 162.6 |
| B | 3 | 64 | 70205 | 458.13 | 807 | 786 | 151.5 |
| B | 5 | 65 | 31820 | 204.81 | 807 | 786 | 151.5 |
| B | 4 | 173 | 26269 | 168.18 | 807 | 786 | 151.5 |
| C | 14 | 238 | 123564 | 666.72 | 794 | 801 | 184.1 |
| C | 3 | 233 | 23635 | 124.01 | 794 | 801 | 184.1 |
| C | 0 | 207 | 14617 | 75.03 | 794 | 801 | 184.1 |
| D | 5 | 222 | 2920367 | 16322.49 | 739 | 719 | 178.9 |
| D | 15 | 0 | 132360 | 735.95 | 739 | 719 | 178.9 |
| D | 13 | 172 | 27273 | 148.45 | 739 | 719 | 178.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
