| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_037T01_9000002312_15598cztM0_level2.evt | modeM0/AS1A04_037T01_9000002312_15598cztM0_level2_quad_clean.evt |
| Size (bytes) | 444,968,640 | 97,211,520 |
| Size | 424.4 MB | 92.7 MB |
| Events in quadrant A | 3,110,421 | 625,510 |
| Events in quadrant B | 3,249,876 | 640,131 |
| Events in quadrant C | 3,512,137 | 613,693 |
| Events in quadrant D | 3,153,433 | 603,316 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13605 | 3 |
| B | 0 | 13889 | 2 |
| C | 0 | 14443 | 2 |
| D | 0 | 13932 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6619 | 21 | 0.317268% |
| B | 6619 | 38 | 0.574105% |
| C | 6619 | 81 | 1.223750% |
| D | 6619 | 49 | 0.740293% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7575 | 6620 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7575 | 6620 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7575 | 6620 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7575 | 6620 | 17 | 17 | 0.22% | 0.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 21020 | 124.28 | 801 | 785 | 162.8 |
| A | 0 | 226 | 7056 | 38.52 | 801 | 785 | 162.8 |
| A | 9 | 143 | 7012 | 38.25 | 801 | 785 | 162.8 |
| B | 5 | 65 | 34758 | 219.44 | 806 | 785 | 154.8 |
| B | 0 | 189 | 23063 | 143.9 | 806 | 785 | 154.8 |
| B | 12 | 111 | 18151 | 112.17 | 806 | 785 | 154.8 |
| C | 3 | 233 | 344396 | 1883.09 | 777 | 781 | 182.5 |
| C | 14 | 238 | 119763 | 652.05 | 777 | 781 | 182.5 |
| C | 0 | 207 | 14048 | 72.71 | 777 | 781 | 182.5 |
| D | 12 | 222 | 62042 | 320.48 | 783 | 759 | 191.2 |
| D | 1 | 52 | 40782 | 209.3 | 783 | 759 | 191.2 |
| D | 2 | 234 | 32546 | 166.23 | 783 | 759 | 191.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
